Submersible Effluent Pumps
5
B
www.cranepumps.com
Professional Plumbing
Series EHV
3/4" Spherical Solids Handling
Manual & Automatic
DISCHARGE ............................... 2” NPT, Female, Vertical
LIQUID TEMPERATURE .............77°F (25°C) Continuous
MOTOR HOUSING ......................Cast Iron
PUMP BODY ...............................Cast Iron
IMPELLER: Design ....................Multi-Vane, Vortex
Material ..................Cast Iron
SHAFT ........................................420 Stainless Steel
O-RINGS ...............................Buna-N
HARDWARE ................................300 Series Stainless Steel
PAINT ........................................... Air Dry Enamel
SEAL: Design ....................Single Mechanical, Oil Filled Reservoir
Material ...................Carbon/Ceramic/Buna-N
Hardware -300 Series Stainless
CORD ENTRY..............................20 ft. (6m) Cord with plug and pressure
Gromment for sealing and strain relief
UPPER BEARING........................Single Row, Ball
LOWER BEARING.......................Single Row, Ball
MOTOR: Design ....................Oil Filled
Insulation ...............Class B
SINGLE PHASE...........................Permanent Split Capacitor (PSC)
Includes Overload Protection in Motor
LEVEL CONTROL:
EHV412...................None
EHV412A ................Wide Angle, Mechanical, 20 ft (6m) cord
Pipe Mounted
EHV412VF..............Vertical Float, PVC, Snap Action
EHV412AT ..............Wide Angle, Mechanical, 20 ft (6m) cord
Pump Mounted
Series: EHV
0.5 HP, 3450RPM, 60Hz
DESCRIPTION:
PUMP IS DESIGNED FOR HANDLING SEWAGE
EFFLUENT IN TYPICAL SEPTIC TANK/EFFLUENT
APPLICATIONS
CSA 108 - File No. LR16567
UL 778
NRTL\C
4/04
Testing is performed with
water specific gravity of 1.0
@ 68˚F (20˚C), other fluids
may vary performance
