Butt’s Pumps and Motors - page 1587

96
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from
hub face to shaft end
OEM
OEM Replacement Motors
OEM Replacement Motors
Goodman-Janitrol
Friedrich
Frigidaire
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R52639
1/6
5/1075 208/230 0.80 CCW 4/370 5.5"
4.00" 2.5"×1/2"×3.7"
R.A.C.
1
Part # Watts Spd/RPM Volts Amps Rot
Type
Dia Body
Shaft
Comment
Fig
R4110
23
1/1550
115
0.80
CW SP 3.9"
4.00"
2.5"×5/16"
Agitator
2
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
RFB162
1/3000 208/230 0.50
CW SP 3.3"
8.5"
-
82959000
3
RFB140
1/3450
115
1.40 CCW SP 3.3"
5.6"
-
B28330-01
4
RFB185
1/3000
115
1.30
CW SP Skel
5.80"
-
B1859005, Gaskets
Included
5
RFB590
1/30
1/3000
115
1.40
CW SP Skel
5.44"
-
B40590-00
5
RFB595
1/30
1/3000
115
1.40
CW SP Skel
5.89"
-
B18590-05
5
RFB276
1/30
1/3000
115
1.40
CW SP Skel
5.44"
-
0131M00002P
5
RFB501
1/20
1/3000
115
2.80
CW SP Skel
5.57"
-
22307501
6
Fig.3
Fig.4
Fig.1
Fig.2
Fig.5
Fig.6
