Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from
hub face to shaft end
OEM
OEM Replacement Motors
OEM Replacement Motors
Fig. 1
Fig. 3
Fig. 2
Elmira Woodstoves
Part #
HP Spd/RPM Volts Amps Rot
Dia Body
Shaft
Comment
Fig
RB200T-2
35W
2/1600
115
0.80 CCW 3.3"
3.5"
-
200 CFM Blower
1
R489
1/60
3/1300
115
0.92
CW 3.3"
2.5"
3.6"×5/16"×3.5
1500, 1600
2
RB34
1/55
1/3200
115
0.88
CW 3.3"
6.6"
-
Gen. Replacement
3
Emerson
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R506
1/240
1/1400
115
0.43
CW SP 3.3"
1.90"
2.0"×1/4"
Vent FAN
4
R209
1/45
1/1550
115
0.87
CW SP 3.3"
2.30"
1.5"×5/16"
VENT FAN
4
R742
1/10
3/1080
115
1.40 CCW 4/370 5.0"
3.30" 2.2"×1/2"×2.6"
QUIET COOL A/C 5
R743
1/5
3/1400 208/230 1.60 CCW 5/370 5.0"
3.90" 2.5"×1/2"×3.5"
QUIET COOL A/C 5
R2630
1/3
2/1400 208/230 2.40
CW 6/370 5.0"
4.10"
5.0"×1/2"
F1611, QUIET COOL 6
Fig. 4
Fig. 5
Fig. 6
Fig.7
F.P.E.
(Federal Pioneer - Westcan)
Part #
HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R302
1/100
1/1550
230
0.20
CW
SP
3.3"
2.25"
2.0"×1/4"
L81512W1
7
R511
1/100
1/1350
230
0.28
CW
SP
3.3"
2.10"
2.0"×1/4"
Electric Heaters
7
R217
1/35
1/1450
230
0.50
CW
SP
3.3"
2.40"
1.2"×1/4"
L82116A4
7
