Butt’s Pumps and Motors - page 1643

152 www.rotom.ca
Free-Air Type Fan Blades - Interchangeable Hub
Part # Rot Dia Pitch
93-6-4300 CW 23°
93-6-4301 CCW 23°
93-6-4302 CW 27°
93-6-4303 CCW 27°
93-6-4304 CW 23°
93-6-4306 CW 27°
93-6-4308 CW 23°
93-6-4309 CCW 23°
93-6-4312 CW 23°
93-6-4313 CCW 23°
93-6-4314 CW 27°
93-6-4315 CCW 27°
93-6-4316 CW 23°
93-6-4318 CW 23°
93-6-4320 CW 12°
93-6-4321 CCW 12°
93-6-4322 CW 18°
Part # Rot Dia Pitch
93-6-4941 CCW 18" 27°
93-6-4942 CCW 20" 25°
93-6-4943 CCW
22"
18°
93-6-4944 CCW 27°
Part # Rot Dia Pitch
93-6-4368 CW
18"
27°
93-6-4369 CCW 27°
93-6-4371 CCW 30°
93-6-4372 CW 33°
93-6-4374 CW
20"
24°
93-6-4377 CCW 28°
93-6-4379 CCW 31°
93-6-4382 CW
22"
35°
93-6-4383 CCW 35°
93-6-4384 CW
24"
26°
93-6-4386 CW 33°
93-6-4387 CCW 33°
Part # Rot Dia Pitch
93-6-4324 CW
10"
23°
93-6-4325 CCW 23°
93-6-4326 CW 27°
93-6-4328 CW 33°
93-6-4329 CCW 33°
93-6-4330 CW
12"
23°
93-6-4331 CCW 23°
93-6-4332 CW 27°
93-6-4333 CCW 27°
93-6-4334 CW 33°
93-6-4335 CCW 33­°
93-6-4336 CW
14"
23°
93-6-4337 CCW 23°
93-6-4338 CW 27°
93-6-4339 CCW 27°
93-6-4340 CW 33°
93-6-4341 CCW 33°
3 Blades
2 Blades 3 Blades
4 Blades 4 Blades (cont.)
Part # Rot Dia Pitch
93-6-4342 CW
16"
23°
93-6-4343 CCW 23°
93-6-4344 CW 27°
93-6-4345 CCW 27°
93-6-4347 CCW 33°
93-6-4348 CW
18"
23°
93-6-4350 CW 27°
93-6-4351 CCW 27°
93-6-43531 CCW 33°
93-6-4354 CW
20"
23°
93-6-4355 CCW 23°
93-6-4356 CW 27°
93-6-4357 CCW 27°
93-6-43582 CW 33°
93-6-43592 CCW 33°
93-6-43622 CW
24"
18°
93-6-43632 CCW 18°
93-6-43542 CW 23°
93-6-43652 CCW 23°
93-6-43672 CCW 27°
Features
• 3 or 4 Blade
• 10" - 24" diameter
• High quality heavy duty aluminium blades
• Maximum air delivery, minimum noise
• Zinc and dichromate plated steel spiders
• For motor speeds up to 1725 RPM
Features
• 18" - 24" diameter
• High quality heavy duty aluminium blades
• Maximum air delivery, minimum noise
• Zinc and dichromate plated steel spiders
• For motor speeds up to 1140 RPM
Typical Applications
• Pedestal Fans
• Wall and Roof Exhausters
• Air Circulators
• Window Fans
• Commercial Ventilation
Equipment
• Unit Heaters
Typical Applications
• Air Conditioning Condensers
• Power Roof Ventilators
• Heat Pumps
• Heat Exchangers
• Commercial & Industrial
Equipment
• Unit Heaters
Performance Tables
Order By : Part number or Diameter,
Pitch and Number of blades
Performance Tables
Order By : Part number or Diameter,
Pitch and Number of blades
1 = Rated to 1550 RPM
2 = Rated to 1140 RPM
Pressure (condenser) Type Fan Blades - Interchangeable Hub
Fan Blades
Fan Blades
