158
Part #
Description
92-A8120
3.62" Bolt Circle
92-A8005
4.0" Bolt Circle
Mounting Bases
Motor Mounting Brackets
End-Mount Brackets
Pedestal Type Brackets
4 Bolt Adapter Plate
Skeleton Motor Mounting Adapter Kit
Condenser Fan Rainshields
Blower Hardware
Triangle Brackets
Part #
Description
Height shaft
center to base
92-A8004
45 Adjustible Bracket 4 1/8" - 5 3/8"
92-A8007
A-BR Bracket
-
Part #
Shaft Dia.
Slinger O.D.
92-M3582
1/2"
7"
92-M3584
7 1/2"
92-M3583
5/8"
7"
92-M3585
7 1/2"
Part #
Description
92-A278
Used to match Fedders/Clare rectangular
mounting stud pattern on 5 5/8" motors
Part #
Description
92-A8220
Round Flange/ Round Discharge, 2" outlet
92-A8218
Square Flange/Round Discharge, 2" Outlet
92-A8216
Bezel and Screen, 3 1/2" Bolt Circle
92-A8221
Cushion Ring
Part #
Description
92-A8670
Converts skeleton mount to 3.3" motor
diameter mount. Extends mounting bolts
from 2" to 3" across
Part #
Height shaft center to base
92-A8008
4 1/8"
92-A8009
4 9/16"
92-A8010
5 3/8"
92-A8012
6 1/4"
92-A8013*
6 3/8"
* 50 watt motor bracket
Motor Mounting
