154
Heavy Duty, All Steel Type Fan Blades
Features
• For 1/2" - 1-3/8" bore ranges
• Malleable iron construction
• Two-bolt design
• Two 1/4-20 × 3/4" cap screws
provided
• Packaged individually
Typical Applications
• Commercial Air Conditioning & Ventillation
• Air Handlers
• Cooling Towers
• Agricultural Applications
• Large Unit Heaters
Performance Tables
Order By : Part number or Diameter,
Pitch and Number of blades
* = Furnished with 3/4" fixed bore hub
on discharge side. Comes with 2 set
screws and standard keyway. Key not
included.
Part #
Rot
Dia Pitch
93-5-2186
*
CW
26"
2
38°
93-5-2225
26"
93-5-2241
28"
93-5-2190
36"
93-5-2191
42"
Part # Pitch
67-QH1/2
1/2"
67-QH5/8
5/8"
67-QH3/4
3/4"
67-QH7/8
7/8"
Part #
Discription
92-CD3500
Drive Bolts, Shank & 1 1/4" Hub
92-CD3510
Drive Bolts, Shank & 1 3/8" Hub
92-CD3520
Drive Bolts, Shank & 1 1/2" Hub
92-CD3530
Drive Bolts, Shank & 1 5/8" Hub
92-CD3505*
1 1/4" Hub Only
92-CD3515*
1 3/8" Hub Only
92-CD3525*
1 1/2" Hub Only
92-CD3535*
1 5/8" Hub Only
92-CD3540*
Pin & Drive Bolt
92-CD3555
Set Screw (3/Pkg.)
92-CD3560*
5/32" Allen Wrench
92-CD3565*
1" Sears Adapter
Part #
Pitch
67-QH1
1"
67-QH1-1/8
1 1/8"
67-QH1-3/16
1 3/16"
67-QH1-3/8
1 3/8"
Split Tapered Bushings
Blower Wheel Pullers
Fan Blades / Accessories
*Blower Wheel Puller Kit
92-CD3570
Includes all sizes
plus a carrying case
Fan Blades & Accessories
