153
Part #
Rot
Dia Pitch
93-6-4328
CW
10"
2
33°
93-6-4329
CCW
33°
93-6-4330
CW
12"
2
23°
93-6-4331
CCW
23°
93-6-4334
CW
33°
93-6-4335
CCW
33°
93-6-4388
CW
14"
23°
93-6-4389
CCW
23°
93-6-4390
CW
33°
93-6-4391
CCW
33°
93-6-4392
CW
16"
23°
93-6-4393
CCW
23°
93-6-4394
CW
33°
93-6-4396
CW
18"
27°
93-6-4397
CCW
27°
Part # Rot Dia Pitch
93-6-4227
CW
14"
33°
93-6-4228
CCW
33°
93-6-4229
CW
16" 33°
93-6-0896
CW
18"
33°
93-6-4231
CCW
33°
93-6-0899
CW
20"
33°
93-6-4232
CCW
33°
93-6-4233
CW
22" 33°
93-6-4235
CW
24" 33°
Part # Rot Dia Pitch
93-6-4238
CW
16" 33°
93-6-4240
CW
18"
33°
93-6-4241
CCW
33°
93-6-4242
CW
20" 33°
93-6-4245
CCW
22" 33°
93-6-4246
CW
24"
33°
93-6-4247
CCW
33°
Part #
Dia.
# Of Set
Screwes
93-217-002
5/16"
1
93-217-003
3/8"
1
93-217-004
1/2"
2
93-217-004
5/8"
2
4 Blades
4 Blades (cont.)
Features
• 10" - 26" diameter
• High quality heavy duty aluminium blades
• Maximum air delivery, minimum noise
• Zinc and dichromate plated steel spiders
• For motor speeds up to 1625 RPM
Features
•
14" - 24" diameter
• High quality heavy duty aluminium blades
• 1/2" bore, shaved & staked hub, attached on intake side
• Zinc and dichromate plated steel spiders
•
For motor speeds up to 1625 RPM
Typical Applications
• Air Conditioning Condensers
• Power Roof Ventilators
• Heat Pumps
• Heat Exchangers
• Commercial & Industrial Equipment
• Unit Heaters
Typical Applications
• Air Conditioning Condensers
• Power Roof Ventilators
• Heat Pumps
• Heat Exchangers
• Commercial &
Industrial Equipment
• Unit Heaters
Fits All Interchangeable Hub Type Fan Blades
• Pre-tapped holes with mounting & set screws started
• Packaged 12/carton; Order in multiples of 12/size
• Bore sizes to fit most field applications
• Zinc & dichromate plated alloy steel
• Simple screw design
Performance Tables
Order By : Part number or Diameter,
Pitch and Number of blades
Performance Tables
Order By : Part number or Diameter,
Pitch and Number of blades
Interchangeable Hex Hubs
Pressure (condenser) Type Fan Blades - Interchangeable Hub
Pressure (condenser) Type Fan Blades - Fixed Hub
Part #
Rot
Dia Pitch
93-6-4402
CW
20"
26°
93-6-4403
CCW
26°
93-6-4404
CW
29°
93-6-4406
CW
33°
93-6-4407
CCW
33°
93-6-5736
CW
22"
23°
93-6-5741
CCW
23°
93-6-4408
CW
27°
93-6-4409
CCW
27°
93-6-4411
CCW
35°
93-6-5737
CW
24"
18°
93-6-5738
CW
23°
93-6-5743
CCW
23°
93-6-4412
CW
27°
93-6-4413
CCW
27°
93-6-4414
CW
33°
93-6-4415
CCW
33°
93-6-4416
CW
26"
27°
93-6-4419
CCW
27°
3 Blades
4 Blades
Fan Blades
Fan Blades
