155
Motor Mounting Bases
For 5 1/2" with flat end
shields or use on extended
thru-bolt motors to gain
additional length to fit old
base
For 3½" ht. c/w mounting base, 2 resilient
rings, 2 latch assemblies, 2 end caps and
a slinger
Motor Mounting Accessories
Mounting Bases
92-A240
9" Blowers( 2 1/2" Rings)
92-A241
12" Blowers ( 2 1/2"
Rings)
92-A242
10" Blowers (2 1/2" Rings)
48 Frame Resilient Mount Kit
Base Mounting Adapter Kit
Base Clips
Resilient Clips
Fits 1 3/4" Resilient Rings
Fits 2 1/4" Resilient Rings
Fits 2 1/2" Resilient Rings
Convert Hub to Resiliant Ring
Part # Shaft Height
“A"
92-A8041
2 1/4"
4.4"
92-A8042
2 1/4"
4.6"
Part #
Description
92-A8095
Includes (1) adapter plate w/ mounting ring, (4) split rings, (8)
nuts & (4) lock washers
Part #
Description
92-A8092
Set of 2 alluminium clips for 4.1" motors bases
92-A8094
Set of 2 spring clips for 5.0" motor bases
92-A8096
Set of 2 clips for 5.5" motor bases
92-A8098
Set of 2 clips for 6.5" motor bases
92-A8233
Set of 4 studs and nuts for 11 frame motor
92-A8236
Set of 4 studs and nuts for 21/29 frame motor
Part #
Description
92-A8104
2 1/4" Unbonded cushion ring
92-A8105
2 1/4" Bonded cushion ring
92-A8106
2 1/4" Hubbed to resillient (2 resil. rings, 4 split rings)
92-A8031
2 1/4" Rings to 2 1/2" rings converter (4 split rings)
92-A8103
2 1/2" Unbonded cushion ring
92-A8102
2 1/2" Bonded cushion ring
92-A8107
2 1/2" Hubbed to resillient( 2 Resil. rings, 4 split rings)
Part # Shaft Height
“A"
92-A8035
2 1/2"
4.7"
92-A8043
2 1/2"
5.0"
Part # Shaft Height “A"
92-A8044
2 5/8"
5.3"
92-A8045
5.5"
92-A8076
6.0"
92-A8077
6.5"
92-A8069
3"
5.0"
92-A8078
5.1"
92-A8070
5.3"
92-A8052
3 1/2"
4.0"
92-A8053
4.3"
92-A8054
4.5"
92-A8057
5.3"
92-A8058
5.6"
92-A8059
6.5"
Part # “A"
Fits
92-A8279
8.6"
S1450,
S1454,T2532
92-A8280
8.1"
S1452,
T2532, T2534
92-A8281
11.1"
T2536, T2537
T2539, T2544
92-A8282
10.1" T2542, T2543
92-A8283
9.1" T2538, T2540
Motor Mounting
A
