SECTION
PAGE
DATE
Submersible Effluent Pumps
USA: (937) 778-8947 • Canada: (905) 457-6223 • International: (937) 615-3598
A Crane Co. Company
12
B
Professional Plumbing
4/04
inches
(mm)
Series EH-HT
3/4" Spherical Solids Handling
Single Seal, High Temperature
MODEL NO PART NO HP VOLT/PH Hz RPM
(Nom)
NEMA
START
CODE
FULL
LOAD
AMPS
LOCKED
ROTOR
AMPS
CORD
SIZE
CORD
TYPE
CORD
O.D
inch (mm)
EH512HT
105084 0.5
120/1
60 3450
M 10.6
47.9
14/3
SOW 0.530 (13.5)
EH522HT
105085 0.5
240/1
60 3450
K
5.3
18.5
14/3
SOW 0.530 (13.5)
EH1522HT 105093 1.5
240/1
60 3450
E
9.0
30.6
14/3
SOW 0.530 (13.5)
EH1592HT 105094 1.5 200/240/3 60 3450
H/F
7.8/7.0 29.2/18.7 14/4
SOW 0.570 (14.5)
EH1542HT 105095 1.5
480/3
60 3450
K
3.5
14.6
14/4
SOW 0.570 (14.5)
OPTIONAL - Temperature sensor cord for 3 phase models is 14/3 SOW, .530 (13.5mm) O.D.
IMPORTANT !
1.) PUMP MAY BE OPERATED “DRY” FOR EXTENDED PERIODS WITHOUT DAMAGE TO MOTOR AND/OR SEALS.
2.) THIS PUMP IS NOT APPROPRIATE FOR THOSE APPLICATIONS SPECIFIED AS CLASS I DIVISION I HAZARDOUS LOCATIONS.
3.) INSTALLATIONS SUCH AS DECORATIVE FOUNTAINS OR WATER FEATURES PROVIDED FOR VISUAL ENJOYMENT MUST BE INSTALLED IN ACCORDANCE
WITH THE NATIONAL ELECTRIC CODE ANSI/NFPA 70 AND/OR THE AUTHORITY HAVING JURISDICTION. THIS PUMP IS NOT INTENDED FOR USE IN
SWIMMING POOLS, RECREATIONAL WATER PARKS, OR INSTALLATIONS IN WHICH HUMAN CONTACT WITH PUMPED MEDIA IS A COMMON OCCURRENCE.
4.) MUST USE A
HIGH TEMPERATURE
WIDE ANGLE LEVEL CONTROL IN HIGH TEMPERATURE APPLICATIONS.
