4(2%% 0(!3% s #!34 )2/.
#LASS ) 'ROUP $#LASS )) 'ROUPS & '
Normally-closed thermostats.
SHADED FRAME INDICATES CAST IRON CONSTRUCTION
, Ê - ÊUÊ/ , Ê* - ÊUÊ -/Ê ," Ê , Ê
--Ê ]Ê ,"1*Ê ÊEÊ Ê—
--Ê ]Ê ,"1*-Ê ÊEÊ ÊUÊ7 / Ê " 1 /Ê "8Ê
RPM
App.
F.L.
%
“C”
60
NEMA
Catalogue
Wgt.
Amps
F.L.
Dim.
HP
Hz
Frame
Number
(lbs.)
Voltage
460 V.
Eff.
(Inches)
50
3600 326TS
825102
570
230/460
57.0 93.0 28.87
1800 326T
825103
570
230/460
61.5 94.5 30.37
1200 365T
825139
875
230/460
62.0 94.1 32.50
60
3600 364T
825104
875
230/460
70.5 93.6 29.38
1800 364T
825105
825
230/460
72.0 95.0 31.50
1200 404T
825140
850
230/460
72.0 94.5
75
3600 365TS
825106
875
230/460
87.0 93.6 30.38
1800 365T
825107
875
230/460
89.0 95.4 32.50
1200 405T
825141
1100
230/460
91.0 94.5 37.12
100
3600 405TS
825108
1100
230/460
110.0 94.1 34.12
1800 405T
825109
1100
230/460
114.0 95.4 37.12
1200 444T
825142
1760
230/460
118.0 95.0 41.25
125
3600 444TS
825110
1760
460
137.0 95.0 37.50
1800 444T
825111
1760
460
146.0 95.4 41.25
1200 445T
825143
2050
460
155.0 95.0 43.19
150
3600 445TS
825112
2050
460
167.0 95.0 37.50
1800 445T
825113
2050
460
172.0 95.8 43.19
1200 445T
825144
2150
460
182.0 95.8 43.19
200
3600 445TS
825114
2050
460
222.0 95.4 37.50
1800 445T
825115
2200
460
225.0 96.2 43.19
1200 445T
825145
2300
460
243.0 95.8 51.69
250
3600 449TS*
825146
2200
460
275.0 95.4 47.97
1800 449T*
825147
2200
460
290.0 95.0 51.69
1200 449T*
825148
2500
460
300.0 95.4 51.69
Ê
Ê7 / Ê, Ê - ÊUÊ/ , Ê* - Ê
CAST IRON FRAME
CLASS I, GROUP D—
--Ê ]Ê ,"1*-Ê ÊEÊ ÊÊ
WITH CONDUIT BOX
RPM
App.
F.L.
%
“C”
60
NEMA
Catalogue
Wgt.
Amps
F.L.
Dim.
HP
Hz
Frame
Number
(lbs.)
Voltage
460 V.
Eff.
(Inches)
3
3600 182TC
825068
90
230/460
3.8 86.5 17.12
1800 182TC
825069
91
230/460
4.0 89.5 17.12
1200 213TC
825149
138
230/460
4.4 89.5 20.18
5
3600 184TC
825070
125
230/460
6.2 88.5 17.12
1800 184TC
825071
125
230/460
6.3 89.5 17.12
1200 215TC
825150
155
230/460
6.9 89.5 20.18
7
1
⁄
2
3600 213TC
825072
138
230/460
9.5 89.5 20.18
1800 213TC
825073
138
230/460
10.0 91.7 20.18
1200 254TC
825151
238
230/460
10.2 91.0 23.52
10
3600 215TC
825074
155
230/460
12.0 90.2 20.18
1800 215TC
825075
155
230/460
13.0 91.7 20.18
1200 256TC
825152
263
230/460
13.0 91.0 23.52
15
3600 254TC
825076
238
230/460
18.0 91.0 23.52
1800 254TC
825077
238
230/460
19.5 92.4 23.52
1200 284TC
825153
365
230/460
20.0 91.7 26.30
20
3600 256TC
825078
263
230/460
23.0 91.0 25.27
1800 256TC
825079
263
230/460
25.0 93.0 25.27
1200 286TC
825154
385
230/460
27.0 91.7 27.80
25
3600 284TSC
825080
365
230/460
29.0 91.7 24.94
1800 284TC
825081
366
230/460
31.5 93.6 26.30
1200 324TC
825155
550
230/460
33.5 93.0 28.87
30
3600 286TSC
825156
385
230/460
35.0 91.7 26.44
1800 286TC
825082
385
230/460
37.0 93.6 27.80
1200 326TC
825157
570
230/460
41.0 93.0 30.37
40
3600 324TSC
825158
546
230/460
46.0 92.4 27.37
1800 324TC
825159
550
230/460
51.5 94.1 28.87
1200 364TC
825160
875
230/460
50.0 94.1 31.50
50
3600 326TSC
825161
570
230/460
57.0 93.0 28.87
1800 326TC
825084
570
230/460
61.5 94.5 30.37
1200 365TC
825162
875
230/460
62.0 94.1 32.50
60
3600 364TSC
825163
875
230/460
70.5 93.6 29.38
1800 364TC
825164
825
230/460
72.0 95.0 31.50
1200 404TC
825165
850
230/460
72.0 94.5 31.50
75
3600 365TSC
825166
875
230/460
87.0 93.6 30.38
1800 365TC
825167
875
230/460
89.0 95.4 32.50
1200 405TC
825168
1100
230/460
91.0 94.5 37.12
100
3600 405TSC
825169
1100
230/460 110.0 94.1 34.12
1800 405TC
825170
1100
230/460 114.0 95.4 37.12
1200 444TC
825171
1760
230/460 118.0 95.0 41.25
125
3600 444TSC
825172
1760
460
137.0 95.0 37.50
1800 444TC
825173
1760
460
146.0 95.4 41.25
1200 445TC
825174
2050
460
155.0 95.0 43.19
150
3600 445TSC
825175
2050
460
167.0 95.0 37.50
1800 445TC
825176
2050
460
172.0 95.8 43.19
1200 445TC
825177
2160
460
182.0 95.8 43.19
