Butt’s Pumps and Motors - page 457

Specifications are subject to change without notice
AC Motors
51
8* "- " ‡*,"" Ê "/",-ÊUÊxÇxÊ6" /-
4(2%% 0(!3% s #!34 )2/.
#LASS ) 'ROUP $ˆ#LASS )) 'ROUPS & '
Normally-closed thermostats.
, Ê - ÊUÊ/ , Ê* - ÊUÊ -/Ê ," Ê , ÊÊ
--Ê ]Ê ,"1*Ê ÊEÊ Ê— --Ê ]Ê ,"1*-Ê ÊEÊ ÊUÊ7 / Ê " 1 /Ê "8Ê
RPM App. F.L. % “C”
60 NEMA Catalogue Wgt. Amps F.L. Dim.
HP Hz Frame Number (lbs.) Voltage 575 V. Eff. (Inches)
50 3600 326TS 850712 570 575 45.6 93.0 28.87
1800 326T 850713 570 575 49.2 94.5 30.37
1200 365T 850714 875 575 49.6 94.1 32.50
60 3600 364TS 850715 875 575 56.4 93.6 29.38
1800 364T 850716 825 575 57.6 95.0 31.50
1200 404T 850717 850 575 57.6 94.5 31.50
75 3600 365TS 850718 875 575 69.6 93.6 30.38
1800 365T 850719 875 575 71.2 95.4 32.50
1200 405T 850720 1100 575 72.8 94.5 37.12
100 3600 405TS 850721 1100 575 88.0 94.1 34.12
1800 405T 850722 1100 575 91.2 95.4 37.12
1200 444T 850723 1760 575 94.4 95.0 41.25
125 3600 444TS 850724 1760 575 109.6 95.0 37.50
1800 444T 850725 1760 575 116.8 95.4 41.25
1200 445T 850726 2050 575 124.0 95.0 43.19
150 3600 445TS 850727 2050 575 133.6 95.0 37.50
1800 445T 850728 2050 575 137.6 95.8 43.19
1200 445T 850729 2150 575 145.6 95.8 43.19
200 3600 445TS 850730 2050 575 177.6 95.4 37.50
1800 445T 850731 2200 575 180 96.2 43.19
1200 445T 850732 2300 575 194.4 95.8 51.69
250 3600 449TS* 850733 2200 575 220 95.4 47.97
1800 449T* 850734 2200 575 232 95.0 51.69
1200 449T* 850735 2500 575 240 95.4 51.69
Ê Ê7 / Ê, Ê - ÊUÊ/ , Ê* - Ê
CAST IRON FRAME
CLASS I, GROUP D— --Ê ]Ê ,"1*-Ê ÊEÊ Ê
WITH CONDUIT BOX
RPM App. F.L. % “C”
60 NEMA Catalogue Wgt. Amps F.L. Dim.
HP Hz Frame Number (lbs.) Voltage 575 V. Eff. (Inches)
3 3600 182TC 850736 90 575 3.0 86.5 17.12
1800 182TC 850737 91 575 3.2 89.5 17.12
1200 213TC 850738 138 575 3.5 89.5 20.18
5 3600 184TC 850739 125 575 5.0 88.5 17.12
1800 184TC 850740 125 575 5.0 89.5 17.12
1200 215TC 850741 155 575 5.5 89.5 20.18
71 ⁄2 3600 213TC 850742 138 575 7.6 89.5 20.18
1800 213TC 850743 138 575 8.0 91.7 20.18
1200 254TC 850744 238 575 8.2 91.0 23.52
10 3600 215TC 850745 155 575 9.6 90.2 20.18
1800 215TC 850746 155 575 10.4 91.7 20.18
1200 256TC 850747 263 575 10.4 91.0 23.52
15 3600 254TC 850748 238 575 14.4 91.0 23.52
1800 254TC 850749 238 575 15.6 92.4 23.52
1200 284TC 850750 365 575 16.0 91.7 26.30
20 3600 256TC 850751 263 575 18.4 91.0 25.27
1800 256TC 850752 263 575 20.0 93.0 25.27
1200 286TC 850753 385 575 21.6 91.7 27.80
25 3600 284TSC 850754 365 575 23.2 91.7 24.94
1800 284TC 850755 366 575 25.2 93.6 26.30
1200 324TC 850756 550 575 26.8 93.0 28.87
30 3600 286TSC 850757 385 575 28.0 91.7 26.44
1800 286TC 850758 385 575 29.6 93.6 27.80
1200 326TC 850759 570 575 32.8 93.0 30.37
40 3600 324TSC 850760 546 575 36.8 92.4 27.37
1800 324TC 850761 550 575 41.2 94.1 28.87
1200 364TC 850762 875 575 40.0 94.1 31.50
50 3600 326TSC 850763 570 575 45.6 93.0 28.87
1800 326TC 850764 570 575 49.2 94.5 30.37
1200 365TC 850765 875 575 49.6 94.1 32.50
60 3600 364TSC 850766 875 575 56.4 93.6 29.38
1800 364TC 850767 825 575 57.6 95.0 31.50
1200 404TC 850768 850 575 57.6 94.5 31.50
75 3600 365TSC 850769 875 575 69.6 93.6 30.38
1800 365TC 850770 875 575 71.2 95.4 32.50
1200 405TC 850771 1100 575 72.8 94.5 37.12
100 3600 405TSC 850772 1100 575 88.0 94.1 34.12
1800 405TC 850773 1100 575 91.2 95.4 37.12
1200 444TC 850774 1760 575 94.4 95.0 41.25
125 3600 444TSC 850775 1760 575 109.6 95.0 37.50
1800 444TC 850776 1760 575 116.8 95.4 41.25
1200 445TC 850777 2050 575 124.0 95.0 43.19
150 3600 445TSC 850778 2050 575 133.6 95.0 37.50
1800 445TC 850779 2050 575 137.6 95.8 43.19
1200 445TC 850780 2160 575 145.6 95.8 43.19
