Refrigeration
Suction Accumulators
With Electric Float
These accumulators have a built in electric float switch to provide a warning, or shut down the compressor in case
of a major flood back exceeding the holding capacity of the accumulator. Float switch contacts may be easily
replaced externally without disturbing the refrigerant charge.
Heat Exchanger-Suction Accumulator Combinations
For Ice Making Heat Pumps, A.C.E.S. Or Maximum Heat Transfer
These suction accumulators have been especially designed to provide a maximum amount of heat exchange
surface for use in special applications. It may eliminate the need for a separate heat exchanger.
Suction Accumulators - Electric Float
Part # Vert. Dia. Length
Maximum Refrigerant
Holding Capacity (lbs)
Inlet
Outlet I.D.
Line Size
Weight
(lbs.)
Evap
Temp.
°F
†
Recommended Tons of Refrigeration
R12 R22 R134a R502
R12
R22
R134a R502
Max Min Max Min Max Min Max Min
48-3700F
V 6"
15"
12.8 11.4 11.7 12.1 1 1/8"
14.5
+40 5.0 0.50 9.0 0.75 4.35 0.48 9.0 0.76
+20 3.2 0.44 6.2 0.65 2.88 0.43 6.0 0.65
0 2.1 0.37 4.3 0.56 1.83 0.36 4.0 0.56
-20 1.4 0.20 2.8 0.47 1.21 0.29 2.5 0.47
-40 0.9 0.16 1.8 0.38 0.78 0.15 1.4 0.38
48-3706F
V 6" 20 1/4" 17.6 16.0 16.4 16.6 1 3/8"
21.1
+40 8.0 1.4 17.0 2.0 7.20 1.35 15.0 2.0
+20 6.0 1.2 11.0 1.9 5.40 1.16 10.0 1.9
0 3.8 1.0 7.7 1.6 3.42 0.97 7.0 1.6
-20 2.4 0.9 5.0 1.3 2.16 0.87 4.5 1.3
-40 1.4 0.7 3.0 1.1 1.26 0.68 2.5 1.1
Suction Accumulators 6" or smaller are UL & cUL listed (File # SA2400) • (Hydrogen copper brazed construction)
† Maximum recommended tons based on pressure drop thru Suction Accumulator equivalent to 1/2°F.
† Minimum recommended tons based on oil return thru Suction Accumulator.
Heat Exchanger-Suction Accumulators Combinations
Part # Vert. Dia. Length
Maximum Refrigerant
Holding Capacity (lbs) Suction
Line
I.D.
Liquid
Line
I.D.
Weight
(lbs.)
Evap
Temp.
°F
†
Recommended Tons of Refrigeration
R12 R22 R134a R502
R12
R22
R134a R502
Max Min Max Min Max Min Max Min
48-AC3703
V 4" 10 5/8" 4.4 4.0 4.1 4.2 3/4 3/8 5.3
+60 2.39 0.17 3.78 0.25 2.20 0.16 3.56 0.24
+50 2.15 0.16 3.40 0.24 2.00 0.15 3.20 0.23
+40 1.80 0.15 3.00 0.22 1.62 0.14 2.80 0.22
+20 1.15 0.12 2.10 0.18 1.03 0.11 2.00 0.18
0 0.70 0.11 1.50 0.16 0.63 0.10 1.40 0.16
48-AC3738
V 5"
13"
7.7 7.0 7.2 7.3 7/8 1/2 9.0
+60 3.11 0.40 5.00 0.60 2.70 0.39 5.00 0.60
+50 2.80 0.38 4.50 0.57 2.50 0.37 4.50 0.57
+40 2.50 0.36 4.00 0.53 2.25 0.35 4.00 0.53
+20 1.80 0.31 3.00 0.45 1.62 0.30 3.00 0.45
0 1.00 0.26 2.30 0.39 0.87 0.25 2.00 0.39
48-AC3700
V 6"
15" 12.8 11.4 11.7 12.1 1 1/8 1/2 16.5
+60 6.39 0.58 11.9 0.84 5.50 0.56 11.5 0.84
+50 5.75 0.55 10.75 0.80 5.00 0.53 10.4 0.80
+40 5.00 0.50 9.00 0.76 4.35 0.48 9.00 0.76
+20 3.20 0.44 6.20 0.65 2.88 0.43 6.00 0.65
0 2.10 0.37 4.30 0.56 1.83 0.36 4.00 0.56
Suction Accumulators 6" or smaller are UL & cUL listed (File # SA2400) • (Hydrogen copper brazed construction)
† Maximum recommended tons based on pressure drop thru Suction Accumulator equivalent to 1/2°F.
† Minimum recommended tons based on oil return thru Suction Accumulator.
