Standard Receivers
Fig.
Part #
*Pump
Down
Capacity
Diameter &
Length Over
End Cap
Inlet Size
Outlet Size Mount
Fusible
Plug
Weight
(lbs.)
A
48-2030
2 lb.
3 x 10
1/4 ID Sweat
1/4 ID Sweat
Vert.
N/R 2.4
B
48-1947
3 lb.
3 1⁄2 x 9 3/8 ID Sweat
3/8 SAE Valve Horz.
R 3.3
C
48-5774
2 lb.
3 x 10 1/4 SAE Fitting 1/4 SAE Valve
Vert.
P
3.0
48-1911
10 lb.
6 x 12 3/8 SAE Fitting 3/8 SAE Valve
10.9
48-1917
3 lb.
3 1⁄2 x 10
1/4 SAE Fitting 1/4 SAE Valve
3.5
48-1918
6 lb.
5 x 10
7.2
48-1920
2 lb.
3 1⁄2 x 7 1⁄2
2.9
48-1921
4 lb.
4 x 10
4.5
48-3212
16 lb.
6 x 18 1/2 SAE Fitting 1/2 SAE Valve
15.6
48-5315
6 lb.
5 x 10 3/8 SAE Fitting 3/8 SAE Valve
7.3
48-9017
3 lb.
31⁄2 x 10
1/4 ID Sweat 1/4 ID Sweat Valve
3.5
48-9021
4 lb.
4 x 10
4.5
48-9027
16 lb.
6 x 18
1/2 ID Sweat 1/2 ID Sweat Valve
15.6
48-9028
2 lb.
3 x 10
1/4 ID Sweat 1/4 ID Sweat Valve
N/R 3.0
48-6801
10 lb.
6 x 12
3/8 ID Sweat 3/8 ID Sweat Valve
P
10.9
48-6848
6 lb.
5 x 10
7.3
D
48-1915
12 lb.
5 x 18
1/4 Sweat
3/8 SAE Valve
Horz.
R
11.4
48-1916
8 lb.
4 x 19
1/4 SAE Valve
7.5
48-1919
19 lb.
5 x 28
3/8 Sweat
3/8 SAE Valve
16.6
E
48-1922
15 lb.
5 x 23
14.5
48-1923
15 lb.
5 x 23
1/2 Sweat
1/2 SAE Valve
15.0
* 90% at 90° for R22, R134a and R502 • For R12, multiply by 1.1 • For R402b, R404a and R406a, multiply by 0.9
UL & cUL listed (File # SA2400) • 500 psi Working pressure • P - Permanent R - Removable
E
48-1923
Horizontal
B
48-1947
Horizontal
C
48-1911
Vertical
Shell & Coil Type Condenser - Receivers
Shell & Coil Type Condenser - Receivers
Part #
Length
Over End
Caps
Dia. Tons
†
Refrig.
Inlet
Refrig.
Outlet
Leek Pruf
Fusible
Plug
Water
Connections
*Pump
Down
Capacity
Weight
(lbs.)
49-5803
14
5 1/2
3/8 Flare
1/4 Valve
R
1/2 SAE Fem.
flare
7 lbs.
18.0
49-5806
6
3/4
3/8 Valve
11 lbs.
22.0
49-5802
16 1⁄4
1
14 lbs.
26.0
49-5804
24
1 1⁄2
19 lbs.
30.0
49-5808
36
3 1 1⁄4 - 12
Rotalock
1 1⁄4 - 12
Rotalock
3/4 OD
30 lbs.
49.0
49-5809
40
5
36 lbs.
59.0
* 90% at 90° for R22, R134a and R502 • For R12, multiply by 1.1 • For R402b, R404a and R406a, multiply by 0.9
† Tons rating for 105°F water delivery • UL & cUL listed (File # 2400) • P - Permanent R - Removable
Backed By A Reputation For Quality & Service!
Used widely by OEM’s throughout the industry, these receivers are available in a broad
range of types and sizes. These receivers are hydrogen brazed for cleanliness and
pressure tested for reliability. A 430° fusible plug is installed on all receivers except the
48-2030
&
48-9028
.
Shell & Coil Type Condenser - Receivers
• These horizontal condenser - receivers are processed to insure
cleanliness & reliability
• Water circulates through finned copper tubes.
• Capacities conservatively rated.
• UL and cUL listed (File # SA2400)
49-5808
Horizontal
Receivers
