Butt’s Pumps and Motors - page 1048

43
Refrigeration
Rotalock Fitting Receivers
Angle
Adapter
Straight
Adapter
Vertical
Valve
Horizontal
Valve
Receivers
• Hydrogen copper brazed construction insuring maximum cleanliness
and strength.
• Horizontal or vertical mounting
Part #
*Pump
Down
Capacity
Diameter &
Length Over
End Cap
Inlet
Size
Outlet
Size
Mount
Leek Pruf
Fusible
Plug
Weight
(lbs.)
48-3392
4 lb.
4 x 10
1"
Rotalock
Fitting
1"
Rotalock
Fitting
Horz.
or Vert.
R
4.7
48-3388
6 lb.
5 x 10
7.3
48-3390
13 lb.
5 x 20
12.3
48-3389
10 lb.
6 x 12
11.1
48-3413
16 lb.
6 x 18
14.5
48-3391
22 lb.
6 x 24
18.3
48-3387
28 lb.
6 x 30
22.0
* 90% at 90° for R22, R134a and R502 • For R12, multiply by 1.1 • For R402b, R404a and R406a, multiply by 0.9
UL & cUL listed (File # SA2400) • 500 psi Working pressure • P - Permanent R - Removable
NOTE
: Rotalock receivers do not include valves or fittings, but are supplied with Teflon gasket installed.
Available valves and fittings for above receivers
Primore Valve Numbers
(horizontal)
Primore Valve Numbers
(vertical)
Primore Angle Adapter
Primore Straight Adapter
Numbers
49-27718
3/8 SAE flare
49-27742
3/8 SAE flare
49-24957
3/8 SAE flare
49-24246
3/8 ID Sweat
49-27689
1/2 SAE flare
49-27035
1/2 SAE flare
49-24958
1/2 SAE flare
49-24247
1/2 ID Sweat
49-27691
5/8 SAE flare
49-27036
5/8 SAE flare
49-24959
5/8 SAE flare
49-24248
5/8 ID Sweat
49-23075
3/8 ID Sweat
49-24606
3/8 ID Sweat
49-24252
3/8 ID Sweat
49-24601
1/2 ID Sweat
49-24490
1/2 ID Sweat
49-24253
1/2 ID Sweat
Primore Teflon Gasket
49-24602
5/8 ID Sweat
49-24491
5/8 ID Sweat
49-24254
5/8 ID Sweat
49-24591
-
Water Chiller Evaporators
Vertical
(for capillary systems)
• Designed for heat pump applications with capillary systems.
• Water flows through integral finned copper tubing and the liquid
refrigerant boils on the outside of the coil.
• May be used in parallel
• Built-in suction accumulator protects the compressor against flood back
and prevents oil trapping
Part #
Size
(Tons)
Depth Height
Refrigerant
Connections
Water
Connections
Weight
(lbs.)
In
Out
49-5829
1
6"
13 1/2"
1/2" ID 3/4" ID 5/8" OD 27.5
49-5830
1 1/2 6"
18"
1/2" ID 3/4" ID 5/8" OD 35.5
49-5971
3
6"
30"
1/2" ID"
3/4" ID 7/8" OD 43.0
Horizontal
(for Expansion Valves)
• Designed for use with thermostatic or automatic expansion valves.
• Water flows through integral finned copper tubing and the liquid
refrigerant boils on the outside of the coil.
Part #
Size
(Tons)
Depth Length
Refrigerant
Connections
Water
Connections
Weight
(lbs.)
In
Out
48-5011
3
6"
26"
5/8" ID 1 1/8" ID 5/8" ID 30.0
48-5012
5
6"
35"
7/8" ID 1 3/8" ID 1 1/8" ID 43.0
† Tons rating for 105°F water delivery. • UL & cUL listed (File # SA2400)
L
D
Vertical
48-3390
Illustrated
48-5011
Horizontal
H
D
Receivers
