Heating & A/C
Original Replacement Gaskets - Beckett, Carlin & Wayne
The below gaskets are the original OEM gaskets for the below
specified burners. Guaranteed to work in the application! For gasket
specifications please contact the OEM directly.
Part #
Description
Specifications
Models
63-3616
Beckett universal gasket. 8 1/2" OD × 3 15/16" ID Universal
63-12484
Wayne flange gasket.
7 3/8" OD × 4 5/16" ID EH, EASR & EHA.
63-100428
Wayne flange gasket.
7 1/2" OD × 4" ID
HS, HSR & HSG.
63-75016
Carlin flange gasket.
8" OD × 3 1/8" ID
99-101 CRD & EZ1.
Replacement Burner Gaskets
General Replacement Burner Gaskets
These replacement burner gaskets are suitable for a wide variety
of generic burners.
• 1/8" thick white non-asbestos material.
• Continuous operation temperature of 1260°C (2300°F).
Part #
Description
Specifications
Models
63-75009
Carlin flange gasket. 12" OD × 10" ID.
1150.
63-75010
Carlin flange gasket. 11" OD × 8 3/4" ID.
1050.
63-75011
Carlin flange gasket. 11" OD × 5 1/4" ID.
801 pressure fired.
63-75012
Carlin flange gasket. 10" OD × 4 1/8" ID.
301, 501, 601 &
701 pressure fired.
63-75013
Carlin flange gasket. 8 1/2" OD × 5 1/4" ID. 801 STD.
63-75014
Carlin flange gasket. 8 1/2" OD × 4 1/8" ID.
501, 601 & 701
STD.
63-75015
Carlin flange gasket. 8 1/4" OD × 4 1/8" ID. 201 & 301 STD.
63-75005
GE door gasket.
10" OD × 8"ID
Universal.
63-75006
Heil/ Bradford/ Olsen
cover gasket.
3" OD × 2" ID,
Universal.
63-75000
Miller (large) plate
gasket.
16" × 10 1/2"
CMF, MOC & MGC
Miller # 301205000.
63-75001
Miller (small) pouch
gasket.
13 5/8" × 10"
MMG82 Miller #
301181000.
63-75002
Miller burner flange
gasket.
6 1/2" OD × 4 1/4" ID.
CMF & MOC Miller
# 300001000.
63-75017
Miller flange gasket.
12 13/16" × 4 9/16".
MSH Miller #
689505
63-75018
Miller flue gasket.
7 1/8" OD × 5 1/8" ID.
CMF, MOC & MGC
Miller # 301195000.
63-75019
Miller gasket kit.
(1) 63-75000.
(1) 63-75001.
(1) 63-75002.
(1) 63-75018.
CMF, MOC & MGC.
63-75003
Riello air tube gasket. 5 1/4" × 5 1/4"
Universal.
63-75004
Thermo Pride cover
gasket.
4" OD × 3/8" ID.
Universal.
63-75007
Universal gasket - no
bolt holes.
8" OD × 4" ID.
Universal.
63-75008
Utility gasket roll.
25' × 1" roll.
Universal.
63-3616
63-12484
63-100428
63-75016
63-75009
63-75010
63-75011
63-75012
63-75013
63-75014
63-75015
63-75005
63-75006
63-75000
63-75001
63-75002
63-75017
63-75018
63-75019
63-75003
63-75004
63-75007
63-75008
Burner Gaskets
