141
Heating & A/C
"Quick Spin II"
Spin On Fuel Filter - Elements only
• Engineered and designed for high efficiency domestic
fuel oil burners for superior filtration, 10 micron!
• Effectively removes rust, scale and other microscopic
impurities that might hamper burner operation.
• Replaces Gar-Ber
®
R cartridge and mounts on existing
heads or you can use our own (Part # 69-41437).
"Quick Spin II"
Spin On Filter Kit - Elements & Head
• Engineered and designed for high efficiency domestic fuel oil burners
for superior filtration, 10 micron!
• Effectively removes rust, scale and other microscopic impurities that
might hamper burner operation
• Replaces Gar-Ber
®
11-VR cartridge and head mount. (Mounting
brackets & vacuum gauges available - call for price & availability)
"Quick Spin II"
Spin On Filter - Head Mount Only
• Manufactured from cast aluminum.
• Head includes two 3/8" NPT, inlet & outlet ports and a 1/8" NPT gauge
port, loc-tight sealed and plugged (vacuum gauge not included).
• Also includes two 1/4" 20 x 1/2" depth mounting bracket holes.
• Triple sealing action rim provides sure seal every time.
Oil Filters
"Quick Spin II" Spin On Filter Kit
Elements with head.
Part #
Description
Package
69-41439
Kit includes 69-41436
filter with 69-41437 filter
head mount.
6 individual filter elements with
head mount and O-ring post
gaskets.
"Quick Spin II" Spin On Filter Head
Head mount only.
Part #
Description
Package
69-41437
Filter head mount for
69-41436 filter.
1 filter head mount with
plugged gauge port.
69-41436
Illustrated
69-41439
Illustrated
69-41437
Illustrated
"Quick Spin II" Spin On Filter
Elements only.
Part #
Specifications
Package
69-41436
Dimensions:
Canister Type:
Filtering Area:
Filtering Media:
Rated Work Temp.:
Melting Point:
Rated Flow Rate:
Max. Flow Rate:
Rated Work PSI:
Collapse PSI:
Min. Burst PSI:
Micron Rating:
Certifications:
4 5/8" height × 3 7/16" diameter.
Triple corrosion resistant.
550²".
Resin treated cellulose.
140°F.
1100°F.
25 gallons per hour.
120 gallons per hour.
12 psi.
18 psi.
60 psi.
10.
UL & cUL listed.
6
individual
filter
elements
with
O-ring post
gaskets
located
under a
molded
plastic dirt
shield.
Features
• Designed for superior
filtration - 10 microns!
• Contains 10% more
filter media than
traditional filters.
• Epoxy coated bottom
won't rust from water.
• No internal metal parts.
• Flat bottom makes
filters easily stackable.
• Spill proof with supplied
plastic cover.
Quick Spin II Filters
Replace or Fit:
• Gar Ber 11VF-OB.
• Mitco 264-91M.
• Wix 24100.
• Nozzle Guard
NG3300-M.
• Essex.
• Sid Harvey 290-6M.
• Crown Quick Spin I.
Spill
proof with
supplied
plastic
cover.
Flat
bottom.
Oil Filters
