Service Tools
Refrigerant Recovery Machines
Oil-Less Refrigerant Recovery Machine - PRO-SET®
Part #
Features
Specifications
46-CR700
• Powerful 1 HP oil-less reciprocating recovery compressor.
• An exceptional compressor, condensing & cooling system allows
for fast recovery rates in high temperature environments.
• R410A ready with 550 psi high pressure shut-off switch.
• Automatic low pressure shut-off switch turns unit off when recovery
is complete.
• Heavy duty components enclosed in a rugged high density double
walled polyethylene case housing.
• Easy view top mounted controls.
• Externally serviceable valves and gauges.
• Ergonomic - well balanceddesign for easy transport.
• Convenient shoulder strap for easy transportation.
• Compact modular design with easy access 4 bolt latching system.
• Complete compressor rebuild in minutes.
• Oversized piston head & cylinder combined with a 450% larger
discharge port allows the 46-CR700 to achieve the fastest overall
ARI certified recovery rates in its class.
• Built-in suction filter located under suction port.
• No suction valve eliminates failures caused by liquid slugs.
Capacity
• Direct Vapour: Up to 43 kg/h (1.6 lb/min).
• Direct Liquid: Up to 271 kg/h (10 lb/min).
• Push-Pull: Up to 542 kg/h (20 lb/min).
• Operating Temperature: 0°C (32°F) to 49°C (120°F).
• Power Consumption: 850 W
• Suction Pressure Gauge: -76cm hg to 35 kg/cm (-30" hg
to 350 psig).
• Discharge Pressure Gauge: 0 to 55kg/cm (0 to 800 psig).
• Overload protection: 15 amp.
• High Pressure Shut-off: 38 bar (550 psig).
Mechanics
• Compressor: 1HP oil-less reciprocating.
• Voltage: 120V, 50/60hz, 1 Ph.
• Filtration: Cleanable 100 mesh screen integrated into
suction port.
• Shut-off Valves: Both suction and discharge piston
manifold valves.
• Dimensions: 20cm (8") × 37cm (14.5") × 30.5cm (12").
• Weight: 16.3 kg (36lbs).
46-CR700
Illustrated
46-CR700
CYCLONE
Refrigerants
• R12, R134a, R401C, R406A,
R500, R401A, R409A, R401B,
R412A, R411A, R407D, R22,
R411B, R502, R407C, R402B,
R408A, R509, R407A, R404A,
R402A, R507, R407B, R410A.
Applications
• Residential A/C
• Commercial
R410A
Ready!
PRO-SET® CR700 Recovery Machine!
• On the fly self-clearing valve.
• Integrated manifold block system.
• Built-in suction filter located under the suction port.
• Indestructible high-density polyethylene case.
• Comfortable integrated carrying handle and
shoulder strap.
• Worldwide approvals - CSA, CE, TUV-GS.
• UL certified to meet or exceed EPA regulations per
ARI standard 740-95.
Recovery Machines
