Service Tools
Controls Pump
• Quickly and accurately test and set single or dual
pressure controls to 350 psi and 25" of vacuum. Use
with gauge manifold.
Part #
Description
12-40200
Controls pump with 12-40201 adapter.
Replacement Parts
Part #
Description
12-40201
Adapter w/o-ring.
12-40202
Adapter o-ring.
12-40203
Pressure access valve w/35 psi core.
12-40204
Piston o-ring.
12-40205
Pressure valve core 35 psi.
12-40206
Vacuum valve core 3 psi.
12-40207
Vacuum access valve w/3 psi core.
Controls Pump
12-40200
Illustrated
Oil Pumps
Change Oil Pumps
• Removes oil from compressor, marine engines and other equipment.
• Pumping capacity is 10 strokes per quart.
• Suction tube is 5/16" × 15" but lengths up to 60" can be used.
• Not designed to operate under pressure.
Charge Oil Pumps
• It eliminates the possibility of drawing air & moisture into the system
• Built-in check valve prevents you from having to pump down the
system first.
• Measures the oil you are adding (20 strokes = 1 quart).
• Designed to operate at pressures up to 250 PSI.
• Charges without pumping compressor down.
• Reduces charging time by over 70%.
Charge Oil Pumps
Part #
Description
55-1702
1 gallon cans.
55-1703
5 gallon cans.
Change Oil Pump
Part #
Description
55-1751
Change oil pump.
55-1751
Illustrated
Charge Oil Pump Adapters
Part #
Description
55-1768
Adapter kit for all popular cans and bottles of refrigerant oil. Kit contains
5 rings and one spacer to accommodate most oil containers. Supplied
with the 55-1702 and 55-1703 models.
55-1770
Suction adapter for new style aluminum Charge-Oil Pump. Converts
a 55-1702 pump into suction pump for refrigeration, marine and other
similar applications where it is impossible to draw oil in the normal
manner.
THERMAL
55-1768
Illustrated
55-1770
Illustrated
Oil & Control Pumps
