1/4" Forged Bar - Charging & Testing Manifolds
• Pull-out proof
hanging hook.
• Hose holder
mounts to front
or back of bar.
• Wider clearance
between gauges,
allows plenty of
room for protective
boots to be added.
• Surge
dampened
gauges.
• Reduced
pointer
movement.
• Knuckle clearance
- angled bar design.
• Metal hand-wheels.
• Replaceable
intake fittings.
Manifold & No Hose Sets
R12, R22 &
R502
R410A
R134a, R404A
& R507
Description
04-M8-8 04-M7-8 04-M5-8
Manifold.
04-M8-8SG
-
-
Manifold - sight glass.
04-M9-8SG
-
-
Manifold - sight glass & liquid
filled gauges.
Manifold & Enviro-Safe Hose Sets
R12, R22 &
R502
R410A
R134a, R404A
& R507
Description
-
-
04-M5-36
Manifold & 3' hose set.
04-M8-5 04-M7-5 04-M5-5
Manifold & 5' hose set.
04-M8-6 04-M7-6 04-M5-6
Manifold with 3' red, 3' blue & 5'
yellow hose.
04-M8-6SG
-
04-M5-6SG
Manifold with sight glass, 3' red,
3' blue & 5' yellow hose.
04-M9-6SG
-
-
Manifold, sight glass, liquid
gauges, 3' red, 3' blue & 5'
yellow hose.
Manifold & Secure-Seal Fitting Hose Sets
R12, R22 &
R502
R410A
R134a, R404A
& R507
Description
04-M8-5S
-
04-M5-5S
Manifold & 5' secure-seal.
Manifold & Ball Valve Shut-Off Hose Sets
R12, R22 &
R502
R410A
R134a, R404A
& R507
Description
04-M8-5GY5 04-M7-5GY5 04-M5-5GY5
Manifold & 5' ball valve shut-off
hoses.
R410A manifolds with 5/16" fittings available upon request.
Features
• Manifold offers a heavier, more durable, forged
body than the standard bar. Ideal for high
pressure refrigerants.
1. Stem seats retract completely to provide full flow.
2. Zero leakage high pressure raised seat for
positive sealing.
3. Double size flow path throughout length of centre
port.
1
2
3
Manifold Replacement Parts
• 04-M5, M6, M7, M8 & M9 Series
No.
Part #
Description
1
04-MR503
Hand-wheel screws (2).
2
04-MR508
Metal hand-wheel.
3
04-MR516
Stem assembly & nut.
4
04-MR509
02-P90019
O-rings (2).
R134a o-rings (5).
5
04-MR505
04-MRA505
Piston w/seat & o-rings.
R134a piston w/seat & o-rings.
6
04-M2-300
04-MR521
Hose holder.
Acme hose holder.
7
04-M2-102N
Hanging hook.
8
04-MR520
Sight glass.
9
02-U1-4B
02-AF13450
Intake fitting.
Acme Intake fitting.
-
04-MR519K
Valve Repair Kit
Includes: 04-MR516, 04-
MR505, o-rings & screws.
