Service Tools
Vizi-Vapr Charger
The Vizi-Vapr eliminates the problem of slow vapour charging by
removing the refrigerant from the cylinder as a liquid and injecting it
into the system as a saturated vapour. Since the liquid refrigerant is
removed from the cylinder by its own pressure, no heat is removed
from it and the cylinder does not get cold. Refrigerant blends must be
removed from their containers as a liquid. Many times charging liquid
directly into a system is not feasible. Using the Vizi-Vapr, the blend
can be charged into the system as a saturated vapour without any
composition change. Vizi-Vapr is adjustable from 1/8 ton up to 50 tons.
The operation is completely visible so there is little danger of liquid
entering the system.
Quick Charging Devices
Vizi-Vapr Charger
Part #
Description
55-7701
Adjustable from 1/8 ton to 50 tons.
55-7701RK
55-7701 repair kit.
55-7701
Illustrated
THERMAL
Refrigerant Recovery Pumps
Spooter Refrigerant Recovery Pumps
The original hand operated recovery pump. The Spooter started its
second generation in the year 2000 with the most current certification
ratings standard. Safe and efficient recovery of category III and IV
refrigerants. ARI certified and EPA accepted as a self-contained
recovery device. Field repairable o-ring and seal repair kits available.
Features
Can be used as:
• Control testing pump.
• Oil pump.
• Pressure test pump.
• Vacuum pump.
• Transferring refrigerants from
one cylinder to another.
• ARI certified.
• EPA accepted.
54-SP2
Illustrated
Spooter Refrigerant Recovery Pumps
Part #
Refrigerant
Category
Refrigerant
Type
Liquid
Recovery
Vapour
Recovery
Shut Off
Vacuum
Residual
Trapped
Refrigerant
54-SP2
Category III
R-134a*
1.94 lb/min 0.09 lb/min
10
Hg vac
<0.11
lb/min
R-500*
1.89 lb/min 0.09 lb/min
Category IV
R22*
2.1 lb/min 0.11 lb/min
R407C*
2.29 lb/min 0.09 lb/min
54-SP2M
Metric Model
(Bar/°C)
Category III
R-134a*
0.88 kg/min* 0.04 kg/min
67.46
kpa
<0.05
kg/min
R-500*
0.86 kg/min* 0.04 kg/min
Category IV
R22*
0.95 kg/min* 0.05 kg/min
R407C*
1.04 kg/min* 0.04 kg/min
* = Representative Refrigerants Tested as Specified by Standard.
Category III
- R12, R134a, R401C, R406a, R500.
Category IV
- R401a, R409A, R401B, R412A, R411A,R407D, R22, R411B, R407C, R402B, R408A, R509.
Spooter II & IIM
• Recovers & Transfers.
• Pulls Quick Vacuum.
• Set Pressure Controls.
• Disassembles For Service.
• Rebuild Kits Available.
Use Spooter To Recover
Or Transfer Hot Shot
R414B!
