Service Tools
R12, R22 & R502 Compound Gauges (°F)
• 30" vacuum to 120 psi, retard to 350 psi.
Part #
Description
04-M2-250
Blue - plastic case.
04-M2-250B
Brass - brass plated metal case.
04-M2-250C
Chrome - chrome plated metal case.
04-M2-250LF
Blue - plastic case, liquid filled.
R12, R22 & R502 Pressure Gauges (°F)
• Pressure from 0 to 500 psi.
Part #
Description
04-M2-500
Red - plastic case.
04-M2-500B
Brass - brass plated metal case.
04-M2-500C
Chrome - chrome plated metal case.
04-M2-500LF
Red - plastic case, liquid filled.
R12, R22 & R502 Metric Gauges (°C)
• 30" vacuum to 120 psi, retard to 350 psi.
• Pressure from 0 to 500 psi.
Part #
Description
04-29260
KPA/PSI, °C compound gauge.
04-29263
KPA/PSI, °C pressure gauge
R410A Gauges
• Low side 30" vacuum to 250 psi, retard to 500 psi.
• High side 0 to 800 psi.
• Pink tint gauge face.
Part #
Description
04-M2-410
Compound gauge.
04-M2-415
Pressure gauge.
R134a Gauges - Automotive
• Pressure from 0 to 500 psi.
• 30" vacuum to 120 psi, retard to 350 psi.
• Blue tint gauge face.
Part #
Description
04-M2-350
Compound gauge.
04-M2-355
Pressure gauge.
R134a, R404A & R-507 Gauges
• Pressure from 0 to 500 psi.
• 30" vacuum to 120 psi, retard to 350 psi.
• Blue tint gauge face.
Part #
Description
04-M2-420
Compound gauge (°F).
04-M2-425
Pressure gauge (°F).
04-29290
Bar/PSI compound gauge (°C).
04-29295
Bar/PSI pressure gauge (°C).
Identical top quality gauges used on J/B manifold sets. Gauges are sensitive
instruments and should not be subjected to pressures beyond scale.
Manifold Gauges
All J/B Gauges Feature
• Full Size Brass Movement.
• Colour Coded refrigerant Scales.
• Pointer Flutter & Surge Dampened.
• Recall Screw.
• Screw-on High Impact Clear View Lexan Lens.
• 1/8" MPT Connection
For safety reasons, gauges and hoses not specified for R410A can damage
product and cause serious injury.
04-M2-425
Illustrated
04-M2-500LF
Chrome Plating
Liquid Filled
04-M2-420
Illustrated
04-M2-250
Illustrated
04-M2-500
Illustrated
04-M2-355
Illustrated
04-M2-350
Illustrated
04-29260
Illustrated
04-29263
Illustrated
04-M2-415
Illustrated
04-M2-410
Illustrated
Manifolds
