1-Valve Diaphragm Aluminum Manifolds - 1⁄4" SAE Fittings
PRO-SET One Valve Manifolds
• Anodized aluminum block body.
• One full turn open or close valve.
• Super strong 100% virgin Teflon diaphragms.
• Excellent vacuum characteristics.
• No-flutter gauge design.
• Extra large knobs for easy grip.
Two Valve Diaphragm Manifolds
Manifold - Low Side
Part # 46-M1CL 46-M1DL
Manifold - High Side
Part # 46-M1CH 46-M1DH
Refrigerant R12, R22, R502. R134a, R404A, R507.
Pressure (Units) PSI (°F) PSI (°F)
Gauge Size 66mm (2.5") 66mm (2.5")
High Gauge Part # 46-RGCH 46-RGDH
Low Gauge Part # 46-RGCL 46-RGDL
One Valve Diaphragm Manifolds
Manifold R410A Manifolds
Part # 46-M2C 46-M2M* 46-M3R*
Manifold & (3) - 90cm (3') Hoses
Manifold & (3) -
150cm (5') Hoses
Part # 46-M2CS3 46-M2MS3* 46-M3RP5*
Manifold & (3) - 150cm (5') Hoses
Manifold & (3)
150cm (5') Hoses
(Ball Valve On End)
Part # 46-M2CS5 46-M2MS5* 46-M3R5E*
Refrigerant R12, R22, R502. R134a, R404A, R507. R410A.
Pressure (Units) PSI (°F) PSI (°F) PSI/ kPA (°C & °F)
Gauge Size 66mm (2.5") 80mm (3.5")* 80mm (3.5")
High Gauge Part # 46-RGCH 46-RGMH* 46-RGRH*
Low Gauge Part # 46-RGCL 46-RGML* 46-RGRL*
* Designates Oil Filled Gauges
2-Valve Diaphragm Aluminum Manifolds - 1⁄4" SAE Fittings
PRO-SET Two Valve Manifolds
• Anodized aluminum block body.
- R410A body colour coded pink.
• One full turn open or close valve.
• Oversized sight glass for easy viewing.
• Excellent vacuum characteristics.
• No-flutter gauge design.
• Extra large knobs for easy grip.
46-M1CH
High Side
46-M2C
Illustrated
46-M2MS5
Illustrated
46-M1CL
Low Side
Manifolds
