40
Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
Fig. 12
Fig. 11
Dunham Bush
Emerson (Quiet Kool)
Fedders
Dundas Greenhouse
Part # HP Volts Amps Type RPM Rot. Body Dia Bearing Cap Shaft
Comments Fig
R1-R124
1/20
120
1.60 SP 1/1550 CCW 2.7" 3.3"
Ball
-
0.90" Hubless
350044, 46, MM2847
2
R1-R125
1/20
230
0.75 SP 1/1550 CCW 2.7" 3.3"
Ball
-
0.90" Hubless
350043, 45, MM2848
2
R6-R42811
1/8
120
2.70 PSC 1/1050 CCW 4.0" 5.5" Sleeve Inc
4.8" × 1/2"
350014, 16, E310025
3
M5-S1510
3/4
200/230/460 2.30 PSC 1/1075 Rev 12.2" 5.5"
Ball
20/370 3.5" × 1/2"
371027
4
UE-9428
1
575
1.60 3 Ph 1/1100 Rev 7.5" 6.5"
Ball
-
1/2" × 2 3/4"
0371025
5
M5-T1540
1
575
2.30 3 Ph 1/1140 Rev 11.5" 5.5"
Ball
-
4.0" × 5/8"
371025, T1538
6
M5-T2158
2
208/230/460 6.00 3 Ph 1/1750 Rev 11.6" 6.5"
Ball
-
2.3" × 7/8"
390080
6
M5-T2166
2
208/230/460 8.40 3 Ph 1/1750 Rev 12.6" 6.5"
Ball
-
2.3" × 7/8"
390082,87,88
6
Part # HP Volts Amps Type RPM Rot. Body Dia Bearing Cap Shaft
Comments Fig
M4-R742
1/10
115
1.35 PSC 3/1080 CCW 3.37" 5.0" Sleeve 4/370 3.5"×1/2"×4"
OEK6511
7
M4-R743
1/5
208/230 1.60 PSC 3/1400 CCW 3.8" 5.0" Sleeve 5/370 3.5"×1/2"×4"
OEK4510
7
M4-R2630
1/3
208/230 2.40 PSC 1/1400 CW 4.12" 5.0" Sleeve 6/370 5.0" × 1/2"
M15010
8
Part # HP Volts Amps Type RPM Rot. Body Dia Bearing Cap
Shaft
Comments
Fig
M4-R2580
1/6
115 2.0 PSC 3/1625 CCW 3.62" 5.0" Sleeve 10/370 3.6"×1/2"×6.8"
M15580-3
9
M4-R740
1/6
230 2.2 SP 2/1050 CCW 3.12" 5.0" Sleeve
-
2.8"×1/2"×4"
S196-00161-003,
S196-00161-016
10
M4-R22180
1/5
230 1.3 PSC 1/1080 CCW 3.87" 5.5" Sleeve 7.5/370 4.25" × 1/2"
S196-179-1, S196-HP127-1,
S196-KP127-1, S196-66-1,
D882, 7126-0320
11
M4-R2339
1/5
208/230 1.5 PSC 2/1350 CCW 3.37" 5.0" Sleeve 4/370 3.6"×1/2"×2.7"
S202-00028-00,
11-33-90000-003,
F42B11A23,
12
M1-R52289
1/3
208/230 2.2 PSC 3/1400 CCW 4.87" 5.5" Sleeve 7.5/370 3.2"×1/2"×6.5"
S202-00034-002
F48F32A23
11-28-90000-004
13
Part # HP Volts Amps Type RPM Rot. Body Dia Bearing Cap Shaft
Comments Fig
FB-RFB500
1/30
115
1.1
SP 1/2860 CCW 5.5" 3.3" Sleeve
-
-
Dundas Foundry Cooler
Blower Fan D500, UE9492
1
Fig. 1
Fig. 4
Fig. 3
Fig. 6
Fig. 7
Fig. 8
Fig. 2
Fig. 5
Fig. 9
Fig. 10
Fig. 13
OEMReplacementMotors
"N" - New Product
