49
Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
Ref Plus
Part #
HP Volts Amps Type RPM Rot. Body Dia BearingCap Shaft
Comments
Fig
EC-34W115-V1543
34W
115 1.60 SP 1/1550 CW 3.55"
-
Sleeve -
Hubless
RMT0004
1
EC-34W230-V1542
34W
230 0.80 SP 1/1550 CW 3.55"
-
Sleeve -
Hubless
RMT0005
1
R3-R368
1/20
115 2.0 SP 1/1550 CW 2.75" 3.3" Sleeve - 2.5"× 5/16"
RMT0011, JA2N267N, 7173-1539
2
R3-R369
1/20
208/230 0.9 SP 1/1550 CW 2.75" 3.3" Sleeve - 2.5"× 5/16"
RMT0012, JA2N268N, 7173-1538
2
Remington Singer
Part # HP Volts Amps Type RPM Rot. Body Dia Bearing Cap Shaft
Comments
Fig
M4-R2675
1/30
208/230 0.4 PSC 4/1075 CCW 3.8" 4.75" Sleeve 2/370 7.7"×1/2"×7.7"
American Air Filter-Singer
Climate Control 02024224
3
M2-R139
1/8
208/230 2.2 PSC 1/1075 CW 4.0"
5.5"
Sleeve 4/5/370 9.0"×1/2"
Remington Singer 21662R,
Franklin 74007
4
Tecumseh
Part # HP Volts Amps Type RPM Rot. Body Dia Bearing Cap Shaft
Comments
Fig
UE-9488
1/20
115 1.70 SP 1/1500 CW 4.875" 3.3"
Sleeve
-
2 1/8"× 5/16"
TMF191, TFM265, 810E019A080,
EM F33HXGFG-2876
5
M4-R2372
1/20
230 1.10 SP 1/1550 CW 3.0"
5.0"
Sleeve
-
2.8"× 3/8"
Tecumseh TFM372, 8105037B01,
326P137, Copeland
6
M4-R2601
1/15
230 1.30 SP 1/1500 CW 3.0"
5.0"
Sleeve
-
2.75"×5/16"
810S050A99, 326P136
6
UE-981
1/15
460 0.60 SP 1/1550 CW 4.25" 3.3"
Sleeve
-
2.5"×5/16"
810G037A47, Fasco D475
GE 5KSP11FG1197CS
7
UE-9487
1/12
230 1.30 sp 1/1500 cw 4.875" 3.3"
Sleeve
-
2 1/8" × 5/16"
TFM262, 810E026A81,
EM F33HXDJ-3668
5
M2-R31862
1/4
230 1.90 PSC 1/1625 CW 4.375" 5.5"
Ball
4/370 2.75"×1/2"
TFM1862, 8330,
KA55HXKGD8330
8
M2-R31864
1/4
460 0.80 PSC 1/1625 CW 4.375" 5.5"
Ball
4/370 2.75"×1/2"
TFM1864, 8331
KA55HGE8331
8
Fig. 4
Fig. 6
Fig. 1
Fig. 2
Fig. 3
Fig. 5
Part # Watts Volts Amps Type RPM Rot. Body Frame Bearing Cap Shaft
Comments Fig
O4-R5211
4
120
0.29 SP 1/1550 CW 4.50"
3.8"
Unit
-
Hubless
TFM41
9
O4-R5311
6
120
0.36 SP 1/1550 CW 2.80"
3.5"
Unit
-
Hubless
TFM61
9
O4-R5421
9
208/230 0.29 SP 1/1550 CW 2.80"
3.5"
Unit
-
Hubless
TFM91
9
O4-R5411
9
120
0.58 SP 1/1550 CW 2.80"
3.5"
Unit
-
Hubless
TFM62, 92
9
O4-R3512
35
208/230 0.70 SP 1/1550 CW 3.50"
3.8"
Unit
-
Hubless
TFM352
10
O4-R3511
35
120
1.40 SP 1/1550 CW 3.50"
3.8"
Unit
-
Hubless
TFM351
10
O4-R5122
50
208/230 0.85 SP 1/1550 CW 4.00"
3.8"
Unit
-
2.0"×5/16"
TFM502
11
Fig. 11
Fig. 10
Fig. 7
Fig. 8
Fig. 9
OEM Replacement Motors
"N" - New Product
