44
Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
Intercity
Keeprite (cont. next page)
Part # HP Volts Amps Type RPM Rot. Body Dia Bearing Cap Shaft
Comments Fig
M3-R2609
1/30
115
1.21 SP 1/1550 CW 3.0" 4.1" Sleeve
-
2.4"×1/2"
Intercity, UE 009
1
M3-R2612
1/30
115
1.21 SP 1/1550 CCW 3.0" 4.1" Sleeve
-
2.4"×1/2"
Intercity, UE 010
1
Part # HP Volts Amps Type RPM Rot. Body Dia Bearing Cap Shaft
Comments Fig
R3-R291
1/35
115
1.2 SP 1/1550 CW 2.50" 3.3" Sleeve
-
1.8"×1/4"
Keeprite 11796-8, 8353710210
2
R3-R291
1/30
115
1.1 SP 1/1550 CW 2.80" 3.3" Sleeve
-
1.6"×1/4"
Keeprite 1043291
3
R3-R360
1/30
115
1.0 SP 1/1550 CW 2.50" 3.3" Sleeve
-
1.625"×1/4"
Keeprite 504249
3
M3-R2811
1/20
115
2.1 SP 1/1050 CCW 2.8" 5.0" Sleeve
-
2.1"×1/2"
Keeprite Ref. 28110,
7151-2253C
4
R3-R370
1/20
115
0.8 Inc.
1/1550 CW 3.84" 3.3" Sleeve
Inc.
2.81"×5/16"
Keeprite 505124, Fasco
7190-2366
5
R3-R371
1/20
208/230 0.4 Inc.
1/1550 CW 3.84" 3.3" Sleeve
Inc.
2.81"×5/16"
Keeprite 505125, Fasco 7190-
2367, A.O. Smith JE2G052
5
R3-R1052
1/20
115
2.0 SP 1/1550 CCW 2.81" 3.3"
Ball
-
2.85"×5/16"
Keeprite 1043336, Fasco
7163-8722N, A.O. Smith
JA2Y016-M, Rotom R358
6
R3-R1053
1/20
230
1.0 SP 1/1550 CCW 2.81" 3.3"
Ball
-
2.85"× 5/16"
Keeprite 1043766, Fasco
7163-8861M, A.O. Smith
JA2Y017-N
6
M3-R2817
1/20
115
1.55 SP 1/1550 CCW 3.30" 4.1" Sleeve
-
2.0"×1/2"
Keeprite 28175,
Fasco 7108-2217C
7
M1-R784
1/20
208/230 0.4 PSC 3/1060 Rev 3.50" 5.5" Sleeve 4/370 2.3"×1/2"
Keeprite 130784
8
M4-R2269
1/15
115
2.40 SP 1/1550 CCW 3.00" 5.0" Sleeve
-
3.0"×1/2"
160269
9
M3-R2657
1/15
230
1.20 SP 1/1550 CW 3.40" 4.3" Sleeve
-
1.8"×3/8"
Keeprite 81335
Fasco 7108-2230C
10
M3-R2658
1/15
115
2.30 SP 1/1550 CW 3.40" 4.3" Sleeve
-
1.8"×3/8"
Keeprite 81356
Fasco 7108-2206C
10
M2-R22576
1/9
208/230 0.6 PSC 2/1060 CW 3.8" 5.5" Sleeve 3/370 2.3"×1/2"
Keeprite Hotel Season
Incremental 128576
11
M4-R2423
1/8
115
1.8 PSC 3/1330 CW 3.4" 5.0" Sleeve 10/370 5.0"×1/2"×2.0"
Keeprite 200423, Rotom R780
12
M2-R31672
1/6
208/230 1.5 PSC 2/1075 CW 4.0" 5.5"
Ball
7.5/370 3.5"×1/2"
Keeprite 171672, 120240
13
M2-R30409
1/5
208/230 1.80 PSC 1/1550 CCW 4.60" 5.5" Sleeve 4/370 3.0" ×1/2"
Keeprite 120409, 1041300,
A.O. Smith HF2J040-N,
Fasco 7124-0021
14
Fig. 1
Fig. 9
Fig. 5
Fig. 4
Fig. 7
Fig. 8
Fig. 3
Fig. 6
Fig. 10
Fig. 12
Fig. 11
Fig. 13
Fig. 14
OEMReplacementMotors
"N" - New Product
Fig. 2
