47
Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
Lennox (cont. from previous)
Part # HP Volts Amps Type RPM Rot. Body Dia Bearing Cap Shaft
Comments Fig
M2-R32117
1/3
208/230 2.00 PSC 1/1075 Rev 6.00" 5.5"
Ball
10/370 6.0"×1/2"
S3050, P-8-9662
1
M1-R52820
3/4
208/230 4.20 PSC 3/1075 CW 7.80" 5.5"
Ball
10/370 5.3"×5/8"×4.8"
31C8102 - Includes Base
2
M2-R32050
3/4
575
1.65 PSC 3/1025 Rev 6.50" 5.5"
Ball
15/370 4.0" × 1/2"
Rooftop Direct Drive Motor
3
M2-R32051
3/4
460
2.15 PSC 3/1075 Rev 6.63" 5.5"
Ball
15/370 4.0" × 1/2"
43G52
3
M5-S7401
1
230
5.0 PSC 1/1075 CCW 5.87" 5.5"
Ball
20/370 4.0" × 5/8"
88C7401
4
M5-S7301
1
460
2.9 PSC 1/1075 CCW 6.5" 5.5"
Ball
15/370 4.0" × 5/8"
88C7301
4
Nutone / Broan
Part # HP Volts Amps Type RPM Rot. Body FrameBearing Cap Shaft
Comments Fig
R7-RB11
1/130
115 0.65 SP 1/3000 CW 0.60" Skel
Sleeve
-
1.7"×7/32"
BF3C-MBB, 118445,
208370856, 67PCF
7
R7-RB109
1/60
115 1.00 SP 1/2400 CW 0.90" Skel
Sleeve
-
1.2"×7/32"
10941067, Broan "BP" Series,
Nutone "RL" Series
8
Nutech
Part # HP Volts Amps Type RPM Rot. Body Dia Bearing Cap
Shaft
Comments Fig
O1-R465
1/15
115
2.3 SP 3/1550 CCW 4.0" 3.3" Sleeve
-
2.3"×5/16"×2.1"
Electrohome 2868-513-133,
152, Nutech Lifebreath 23202
5
M4-R2655
1/12
115
2.3 PSC 1/1550 CCW 3.0" 5.0" Sleeve 5/370 2.5"×3/8"×2.4"
AO812B2355
6
M4-R2324
1/12
115
1.1 PSC 1/1550 CCW 3.0" 5.0"
Ball
Inc 2.5"×3/8"×2.4"
Nubreath 23-204,
GE5KCP298G8560BS
6
Fig. 1
Fig. 8
Fig. 4
Fig. 3
Fig. 6
Fig. 7
Fig. 2
Fig. 5
Fig. 9
Olsen
Part # HP Volts Amps Type RPM Rot. Body Frame Bearing Cap Shaft
Comments Fig
R6-R44587
1/2
115
5.7 PSC 4/1075 CCW 5.25"
5.5"
Sleeve 10/370 3/4" × 1/2"
27836, 26088
9
R6-R44589
3/4
115
11.0 PSC 4/1075 CCW 5.80"
5.5"
Sleeve 20/370 3/4" × 1/2"
27161
9
Rapid Refrigeration
Part # HP Volts Amps Type RPM Rot. Stack Frame Bearing Cap Shaft
Comments Fig
T1-R602
1/125
115 0.50 SP 1/3000 CW 0.65"
Skel
Sleeve
-
1.40"×0.1811" Commercial : 5A140-93 10
Fig. 10
OEM Replacement Motors
"N" - New Product
