43
Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
Hussmann -
cont...
Ideal Evaporator Motor
Part # HP/W Volts Amps Type RPM Rot. Body Dia Bearing Cap Shaft
Comments
Fig
O4-R5711
15 W
115
0.37 PSC 1/1550 CW 3.50" 3.87"
Unit
-
Threaded
301263, 301264, 329646,
400603
1
O4-R5720
15 W
115
0.37 PSC 1/1550 Rev 3.50" 3.87"
Unit
-
Threaded
302555, 254582, 411151
1
R1-R101
9 W
115
0.90 SP 1/1550 CW 2.36" 3.3" Sleeve
-
0.7" Hubless
Evap. Motor
2
R1-R101L
9 W
115
0.90 SP 1/1550 CW 2.36" 3.3" Sleeve
-
0.7" Hubless
Evap. Motor w/ leg mount
3
R1-R103
9 W
115
0.90 SP 1/1550 CCW 2.36" 3.3" Sleeve
-
0.7" Hubless
Evap. Motor
2
R1-R103L
9 W
115
0.90 SP 1/1550 CCW 2.36" 3.3" Sleeve
-
0.7" Hubless
Evap. Motor w/ leg mount
3
EE-5611
9 W
115
0.52 SP 1/1550 CW 3.30" 3.87"
Unit
-
Threaded
47000, 58698
4
O4-R6711
6,9,12 W
115
0.2-0.3 ECM 1/1550 CCW 2.53" 3.87"
Unit
-
Threaded
SVC #110.441.0546
5
EE-5610
6 W
115
0.40 SP 1/1550 CW 3.30" 3.87"
Unit
-
Threaded
38360
4
R4-R3011
1/8
230
1.00 PSC 1/1550 CW 3.75" 5.5" Sleeve 5/370 2.0" × 1/2"
3011
5KSP39DG2221S
5KSP39DG4220AS
6
R4-R30575
1/6
575
0.50 PSC 1/1550 Rev 4.50" 5.5" Sleeve Inc 2.2" × 1/2"
77238
7
R4-R34201
1/5
575
0.50 PSC 1/1075 CW 4.50" 5.5" Sleeve Inc 2.5" × 1/2"
204201
7
R4-R3009
1/5
230
1.60 PSC 1/1075 CW 4.25" 5.5" Sleeve 5/370 3.0" × 1/2"
3009, D805
5KCP39GG3611AS
8
R4-R3012
1/5
208/230 1.40 PSC 1/1075 CW 4.18" 5.5"
Ball
5/370 3.0" × 1/2"
1648,K55CLN1782,
K55HXKWA8573,3008,3012,
5KCP39GG5606S,5KCP39GG765S,
5KCP39GGC052T,5KCP39GN765,
5KSP39GGA967T,P011-96203
9
R6-R49983
1/2
208/230 2.70 PSC 1/1725 CW 5.18" 5.5"
Ball
5/370 3.5" × 1/2"
0644, 644, K644,
K055SME164467,
K55HXCTP9963,
K55HXSME-1644, D890
259983
10
M5-T2538
1
208/230/460 4.10 3 Ph 1/1140 Rev 8.22" 6.5"
Ball
-
5.0"×5/8"
170518, 502595
11
M5-T2540
1
575
1.70 3 Ph 1/1140 Rev 9.10" 6.5"
Ball
-
5.0"×5/8"
170517, KPN502597
11
Part # HP Volts Amps Type RPM Rot. Body FrameBearing Cap Shaft
Comments Fig
T1-R611
1/300
115
0.54 SP 1/1550 CW 0.50" Skel
Sleeve -
2.2" × 0.1811" SM601, 23303, 3008001 12
R1-R108
1/100
115
0.55 SP 1/1550 CCW 1.94" 3.3" Sleeve -
0.70" Hubless 124574, 76108, SM108 13
R1-R123
1/50
115
0.60 SP 1/1550 CW 2.44" 3.3" Sleeve -
0.60" Hubless
76123
13
Fig. 1
Fig.13
Fig. 4
Fig. 3
Fig. 7
Fig. 8
Fig. 12
Fig. 2
Fig. 6
Fig. 5
Fig. 9
Fig. 10
Fig. 11
OEM Replacement Motors
"N" - New Product
