Butt’s Pumps and Motors - page 1475

42 Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
www.rotom.ca
Fig. 1
Fig. 8
Fig. 4 Fig. 3
Fig. 6 Fig. 7
Fig. 2
Fig. 5
Fig. 9 Fig. 10 Fig. 11
Heatcraft
Hill
Hussmann
Part # HP Volts Amps Type RPM Rot. Body Dia Bearing Cap Shaft Comments Fig
US-R90574 1/20 115 1.90 SP 1/1550 CW 2.75" 3.3" Sleeve - 2.48"×5/16" 7136-2113, 253-1194 1
US-R90575 1/20 230 0.89 SP 1/1550 CW 2.75" 3.3" Sleeve - 2.48"×5/16" 7136-3371, 253-1195 1
US-R90573 1/15 208/230 1.20 SP 1/1550 CCW 3.50" 3.3" Sleeve - 3.03"×5/16" 5KSM59LS2262AS, 5034MS,
5008TS 1
US-R90572 1/15 115 1.80 SP 1/1550 CCW 3.00" 3.3" Sleeve - 3.03"×5/16"
5KSM59JSK143S,
5KSM59JS5036S, 5034LS,
5008SS
1
US-R91125 1/12 208/230 0.50 PSC 1/1550 CW 3.66" 3.3" Sleeve 4/370 2.63"×5/16" 7190-0442, 7190-2084,
9656, 7071061, 25309101 2
US-R90721 1/12 115/208/230 1.10 PSC 1/1400 REV 3.62" 3.3" Ball 4/370 3.15"×5/16" 25308601, 25309101,
2531194, 2531195 2
Part # HP/W Volts Amps Type RPM Rot. Body Dia Bearing Cap Shaft Comments Fig
R1-R129 1/55 115 0.70 SP 1/3000 CCW 2.41" 3.3" Sleeve - 0.5" Hubless PP32032E 3
R4-R3001 1/3 208/230 1.80 PSC 1/1625 CW 4.50" 5.5" Sleeve - 3.5" × 1/2" GE3001, PP3955B 4
R4-R3067 1 208/230 7.10 PSC 1/1075 Rev 9.20" 5.5" Ball 15/370 3.8" × 1/2" GE3067, PP19162G 5
O4-R5911 6 W 115 0.40 SP 1/1550 CW 3.40" 3.5" Unit - Threaded PP7577M 6
O4-R5411 9 W 115 0.58 SP 1/1550 CW 2.80" 3.5" Unit - Threaded GE5411 6
EC-HE-0182 10W 115 0.19 ECM 1/1550 CW 3.61" - Ball - Hubless P079441C, P066237A 7
EC-HE-0176 15W 115 0.22 ECM 1/1600 CW 4.00" - Ball - Hubless P078449H 7
O4-R5711 15 W 115 0.37 PSC 1/1550 CW 3.50" 3.87" Unit - Threaded P41661 8
O4-R5720 15 W 115 0.37 PSC 1/1550 Rev 3.50" 3.87" Unit - Threaded P23956 8
O4-R2011 20 W 115 0.80 SP 1/1550 CW 3.75" 3.5" Unit - Threaded PP20934F 5
Part # Watts Volts CFM Type RPM Rot. Body Dia Bearing Cap Shaft Comments Fig
O3-RF2466 14 115VAC 105 - 3000 - - Axial Ball - -
392466
PS2CDB51-125012012
Conair 039865
9
Part # Watts Volts Amps Type RPM Rot. Body Dia Bearing Cap Shaft Comments Fig
O4-R5611 9 115 0.60 SP 1/1550 CW 3.07" 3.87" Unit - Threaded 7000, 58698 10
O4-R5612 9 115 0.60 SP 1/1550 CCW 3.07" 3.87" Unit - Threaded 38360 10
O4-R9211 13 115 0.47 ECM 1/1725 CW 2.53" 3.87" Unit - Hubless 4410547, 441-547 11
OEMReplacementMotors
"N" - New Product
