41
Motors Are Sleeve Bearing Unless Indicated - Rotation Determined Opposite Shaft End (Double Shaft Determined By Lead End)
Habco
Part # HP Volts Amps Type RPM Rot. Stack Dia Bearing Cap Shaft
Comments
Fig
T1-R606
1/134
115 0.50 SP 1/3000 CCW 0.65" Skel
Sleeve -
1.10"×7/32"
H.A. Brown C021795
6
T1-R607
1/49
115 1.3 SP 1/2300 CCW 1.16" Skel
Sleeve -
1.75"×7/32"
H.A. Brown C021617, Bomax 301-6966
6
Fig. 1
GE 11 Frame Replacements
Goodman/Janitrol
Friedrich
Part # HP Volts Amps Type RPM Rot. Body Dia Bearing Cap Shaft
Comments Fig
US-R90671
1/15
115/208/230 2.10 SP 1/1550 CW 5.00 11
Ball
-
2.24"×5/16"
671, 81671
4
US-R90672
1/15
115/208/230 2.10 SP 1/1550 CCW 5.00 11
Ball
-
2.24"×5/16"
672, 81672
4
Part # HP Volts Amps Type RPM Rot. Body Dia Bearing Cap Shaft
Comments Fig
M2-R32251
1/6
208/230
1.0 PSC 1/1075 CCW 3.87" 5.5" Sleeve 5/370 3.75"×1/2"
B13400-251, 4M287,
F48F96A76, F48A90A76,
3216
5
m2-r22247
1/4
208/230
1.5 PSC 1/1075 CCW 4.25" 5.5" Sleeve 5/370 3.25"×1/2"
B13400-247, F48A91A76,
3218, F48F97A76
5
Part # HP Volts Amps Type RPM Rot. Body Dia Bearing Cap Shaft
Comments Fig
M1-R52639
1/6
230
0.8 PSC 5/1075 CCW 4.0" 5.5" Sleeve 4/370 2.5"×1/2"×3.3"
D867, 323P225
2
M1-R62350
1/3
230
1.8 PSC 5/1075 CCW 4.87" 5.5" Sleeve 5/370 2.5"×1/2"2.6"
3002, 5KCP39MG9096S,
5KCP39MG9579S,
5KCP39MG71455,
5KCP39LGG7205,
K4340, D868
3
Fig. 4
Foster
Part # HP Volts Amps Type RPM Rot. Body Dia Bearing Cap Shaft
Comments Fig
R1-R120
1/85
120
0.45 SP 1/1550 CW 2.19" 3.3" Sleeve
-
0.6" Hubless
76120, D425, SM120, 63
1
R1-R119
1/85
120
0.45 SP 1/1550 CCW 2.19" 3.3" Sleeve
-
0.6" Hubless
61,62, D424, SM119
1
R1-R127
1/75
120
0.75 SP 1/1550 CCW 1.94" 3.3" Sleeve
-
1.0" Hubless
2868-505-063
1
R1-R122
1/60
230
0.35 SP 1/1550 CW 2.19" 3.3" Sleeve
-
0.6" Hubless
SM122
1
R1-R121
1/60
230
0.35 SP 1/1550 CCW 2.19" 3.3" Sleeve
-
0.6" Hubless
76121, D430, 64 1
R1-R101
1/45
120
0.90 SP 1/1550 CW 2.19" 3.3" Sleeve
-
0.7" Hubless
76101, SS101,
D437, SM101
1
R1-R103
1/45
120
0.90 SP 1/1550 CCW 2.19" 3.3" Sleeve
-
0.7" Hubless
76103, SS103, D436,
SM103, SM104
1
Fig. 2
Fig. 3
Fig. 5
Fig. 6
OEM Replacement Motors
"N" - New Product
