25
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from hub
face to shaft end
Motors
5.0" Motors
5.0" Motors
Single Shaft-115 Volts - Open & Totally Enclosed
Sleeve Bearing - Shaded Pole & P.S.C.
Part # HP Amps Spd/RPM Rot.
Shaft
Body Encl.
Type
Comment
Fig.
R2360
1/15
1.70 1/1050
C.C.W.
2.8"×1/2 3.59
T.E
S.P.
REZNOR 45330, 45331, 54332,
FASCO D143, U.E. 360
9
R2269
1/15
2.40 1/1050
C.C.W.
3.0"×1/2"
3.00 OPEN S.P.
KEEPRITE 160269, FASCO 7151-
2850, 7151-3862
4
R6920
1/15
2.40 1/1050
C.C.W.
3.0"×3/8"
3.80 T.E.
S.P.
KEEPRITE, INTERCITY,LENNO×
P8-6920
5
R2197
1/14
1.20 3/820
C.C.W.
3.4"×1/2"
3.80 OPEN 7.5/370
TEMSPEC DE3E142N
1
R2194
1/14
1.25 3/820
C.C.W.
3.4"×1/2"
3.22 OPEN
7.5/370
INC.
TEMSPEC DE3E141N
2
R2198
1/14
1.25 3/820
C.C.W.
4.1"×1/2"
3.22 OPEN 7.5/370
TEMSPEC DE3E142N
3
R2195
1/12
2.10 3/740
C.C.W.
4.0"×1/2"
3.60 OPEN
7.5/370
INC.
TEMSPEC DE3F056N
2
R2653
1/12
2.90 3/1050
C.W.
1.6"×1/2"
3.40 OPEN S.P.
GENERAL REPLACEMENT
7
R2654
1/12
3.10 3/1050
C.C.W.
2.5"×1/2"
2.65 OPEN S.P.
G.E. 5KSP29D×1906,FASCO D1054 4
R2930
1/10
4.00 1/1050
C.W
2.3"×3/8"
4.80 OPEN S.P.
G.E. 2121, 2122, 2223, 2321,,2322
Dual Voltage
9
R2932
1/10
4.00 1/1550
C.C.W
2.3"×3/8"
4.80 OPEN S.P.
G.E. 2131, 2132, 2231,2232, 2331,
2332, Dual Voltage
9
R2940
1/10
4.00 1/1050
C.W.
2.3"×3/8"
4.80 OPEN S.P.
G.E. 2113, 2213, 2311,,2312, Dual
Voltage
9
R2942
1/10
4.00 1/1550
C.W.
2.8"×3/8"
4.56 OPEN S.P.
G.E. 2141, 2142, 2241,2242, 2341,
2342, Dual Voltage
9
R2980
1/10
3.20 3/1050
C.C.W.
3.3"×3/8"
3.80 S.E.
S.P.
GENERAL REPLACEMENT
10
R2698
1/10
3.50 1/1050
C.C.W.
2.1"×1/2"
3.00 OPEN S.P.
BROAN A0520B2298, 30080126,
30080135
8
Fig.2
R2195
R2194
Fig.3
R2198
R2654
Fig.1
R2197
Fig.4
R2269
Fig.5
R6920
Fig.6
R2343
Fig.7
R2653
Fig.8
R2698
Fig.10
R2980
Fig.9
R2930
R2932
R2940
R2942
R2360
Motors continued next page
