Motors
5.5" Motors
5.5" Motors
Single Shaft-115 Volts
Sleeve & Ball Bearing - Shaded Pole - PSC - Open & Totally Enclosed
Part # HP Amps Spd/RPM Rot.
Body Shaft
Type Encl. Bearing
Comment
Fig.
R42819
1/8
2.20 1/700
C.W.
6.50 1.5"x1/2" 5/370
OPEN SLEEVE
G.E.3134,
5KCP36KG246,5KCP38NG208,
5KCP39KGB909
1
R42813
1/8
2.40 3/1050
C.C.W.
4.00 4.8"x1/2" INC.
OPEN SLEEVE CARRIER HC35ME104
4
R42811
1/8
2.50 1/1050
C.C.W.
4.00 4.8"x1/2" INC.
OPEN SLEEVE DUNHAM BUSH E310025
4
UH-9034
1/6
2.40 1/1075
REV
4.55 3.4"×1/2" INC
T.E.
BALL
UH1016, US1016, NB, 9034, D834,
3206, X032, X306, 177, 749
2
DD-030
1/6
2.60 5/950
C.C.W.
3.98 4.4"x1/2" INC
OPEN SLEEVE UNILUX 5KCP39DEV2795
5
R12835
1/6
2.00 1/1625
REV.PLUG
4.75 2.8"x1/2" INC.
T.E.
BALL
GEN. REPLACEMENT
1
R12178
1/6
2.00 1/1625
REV.PLUG
5.25 2.8"x1/2" INC.
T.E.
SLEEVE GEN. REPLACEMENT
1
R12834
1/6
2.20 1/1075
REV.PLUG
4.36 2.5"x1/2" INC.
T.E.
BALL
MARATHON X306
1
R12677
1/6
2.80 1/1075
REV
4.36 2.5"x1/2" 5/370
T.E.
SLEEVE
UNIT HEATER
2
R42613
1/6
3.00 3/1050
REV.PLUG
3.60 5.2"x1/2" 7.5/370
OPEN SLEEVE
FRANKLIN 73192, 80192,G.E.
3920, 3980
3
R12177
1/6
3.00 1/1075
REV.PLUG
4.80 2.8"x1/2" INC.
T.E.
SLEEVE
FASCO D834,FRANKLIN 74002,
MARATHON X302, U.E. 177
1
Continued Next Page
Fig.1
