15
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from hub
face to shaft end
Motors
3.3" Motors
3.3" Motors
Open - Double Shaft
Sleeve Bearing - Shaded Pole & P.S.C.
Sleeve Bearing - Shaded Pole & P.S.C.
1550 RPM-115 Volt
Part # Amps.
H.P.
Rotation
Shaft
Body
Feature
Comment
Fig.
R416
0.76
1/60 C.C.W.
2.3"x1/4x2.3" 2.20
Cord & plug
72" leads
1
R701
1.30
1/12 C.C.W. 5.0"x5/16x2.7" 4.60
4 studs front & rear
P.S.C./Cap inc., Window A/C, three
speed
2
R440
1.60
1/20 C.W.
3.8"x5/16x3.8" 3.80
Hex hubs, cord & plug
Nutone
3
Totally Enclosed - Double Shaft
1550 RPM-115 Volt
Part # Amps H.P. Rotation
Shaft
Body
Feature
Comment
Fig.
R408
0.72
1/65 C.C.W. 1.6"x1/4"x1.6"
2.25
Two speed
Lau Products
1
R489
0.74
1/70 C.W.
3.0"x5/16"x3.8"
2.30
Control wires, three speed
Elmira Stove
2
R415
0.85
1/65 C.C.W. 2.3"x1/4"x2.3"
2.92
Int.Fan, cord & plug
Gen. Replacement
2
R510
1.10
1/45 C.W.
1.1"x1/4"x1.5"
2.25
C ring groove, three speed
Camco/Woods
2
R462
1.10
1/17 C.C.W. 3.5"x3/8"x3.5"
4.00
2 studs side, three speed
Venmar HRV 02102 3
R467
1.40
1/25 C.W.
1.8"x5/16"x1.8"
3.10
Hex Hubs, Molex plug
Broan
4
R470
1.40
1/25 C.W.
3.8"x5/16"x3.7"
3.00
Hex Hubs, studs
Nutone
2
R366
1.70
1/7 C.W 3.0"x3/8"x3.0"
4.75
2 studs side, three speed
Venmar HRV 02100 3
R455
1.90
1/25 C.W.
4.6"x5/16"x4.6"
3.20
Three speed
Gen. Replacement
2
R717
2.00
1/15 C.C.W. 5.0"x5/16"x3.5"
3.50
Three speed
Window A/C
2
R729
2.00
1/15 C.C.W. 3.5"x5/16"x5.0"
3.50
Three lugs, three speed
Window A/C
5
R90324
2.10
1/25 CW 1.95"x5/16"x1.95" 2.92
Hex hubs
324, 82324
3
R465
2.25
1/15 C.C.W 2.3"x5/16"x2.3"
4.00
Internal Fan, three speed Nutech/Elmira stoves 2
R439
2.60
1/14 C.C.W. 6.4"x5/16"x6.4"
3.25
4 studs, oilers, two speed
Gen. Replacement
6
Fig. 2
R701
Fig. 3
R440
Fig. 1
R408
Fig. 2
R415
R455
R465
R470
R489
R510
R717
Fig. 3
R366
R462
R90324
Fig. 4
R467
Fig. 5
R729
Fig. 6
R439
Fig. 1
R416
