Motors
Flue Exhaust Motors
Flue Exhaust Motors
Part # HP Spd/RPM Amps Volts Rot
Shaft
Body Type Mntg
Comment
Fig
RFM230
1/12
1/3200 0.60 230
REV.
PLUG
2.5"x1/4" 7.00
P.S.C.
/INC
STUD 024-24115-020, 714
1
RFM9
1/12
1/3000 1.10 208/230
C.C.W.
2.8"x5/16" 6.30
S.P.
STUD KEEPRITE 501493,
2
RFM232
1/10
1/3450 0.55 208/230
C.W.
2.9"x5/16" 5.00
P.S.C.
/INC
STUD
ICP 1171348, JF1H092N
CARRIER HC30GB232
3
RFM410
1/10
1/3000 1.50 115/230
REV.
3.7"x1/4" 7.10
P.S.C.
/INC
LUGS FASCO D410, D412, REZNOR 4
RFM187
1/10
1/3400 0.30 460
C.W.
8.8"x3/8" 6.80
P.S.C.
/INC
STUD
YORK 024-2500-5005,
024-2500-5702, D1187
5
RFM460
1/10
1/3200 0.30 460
REV.
2.5"x1/4" 7.00
P.S.C.
/INC
STUD
YVFM450, FASCO D1171
YORK 024-24115-700
6
RFM78
1/9
1/3200 1.30 115/230
REV.
3.3"x5/16" 4.10
P.S.C.
/INC
STUD
RFM7&8, REZNOR
43846-115V, 43424-208/230V
7
* Note: Without Centrifugal Switch
Fig. 1
RFM230
Fig. 4
RFM410
Fig. 5
RFM187
Fig. 6
RFM460
Fig. 7
RFM78
Fig. 2
RFM9
Fig. 3
RFM232
