Butt’s Pumps and Motors - page 1509

18
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from hub
face to shaft end
Motors
Unit Bearing Motors
Unit Bearing Motors
115 & 230 Volts 1550 &1500 RPM
• Cast Iron (except R5109 & R1211)
Part # Watts Amps Volts Rot
RPM A Dim Shaft
Comment
Fig
R5090
2
0.25 115 C.W.
1550
2.70"
Hubless
CAST IRON 2 WATT CONDENSER MOTOR
1
R5109
0.25 115 C.W.
1550
2.50"
Hubless
GE 5109, WR60X77, 5KSM51AG3070,
5KSP51AZL826
1
R5211
4
0.35 115 C.W.
1550
2.58"
Hubless
TECUMSEH TFM41, G.E. 5211 5KSP51AL511
1
R5212
0.35 115 C.C.W.
1550
2.58"
Hubless
G.E. 5212, 5KSP51AL513
1
R5221
0.20 230 C.W.
1550
2.58"
Hubless
G.E. 5221, 5KSP51AL512, COPELAND 050-0246-00
1
R5222
5
0.20 230 C.C.W.
1550
2.58"
Hubless
G.E. 5222, 5KSP51AL514
1
R5911
0.35 115 C.W.
1550
3.30"
Hubless
COPELAND 050-0010-00,0178-00 050-0246-01,HILL
PP7577
1
R6247
0.35 115 C.W.
1550
3.44"
Hubless
R CORNELIUS
1
R1211
0.30 115 C.W.
1550
2.09"
Hubless
3.3", 199D354HO1, H06, H13, WR60D1, 6550923,
6550928
1
R5311
6
0.50 115 C.W.
1550
2.83"
Hubless
G.E. 5311, 5KSP51CL501, TECUMSEH TFM61
1
R5312
0.50 115 C.C.W.
1550
2.83"
Hubless
5914767, 5914782, G.E. 5312, 5KSP51CL502
1
R6243
0.50 115 C.W.
1550
3.44"
Hubless
CORNELIUS
1
R5411
9
0.60 115 C.W.
1550
2.83"
Hubless
G.E. 5411, 5KSP51ECL551 TECUMSEH TFM91
1
R5412
0.60 115 C.C.W.
1550
3.40"
Hubless
G.E. 5412, 5KSP51ECL553
1
R5421
0.30 230 C.W.
1550
2.83"
Hubless
TECUMSEH TFM62, TFM92, G.E. 5421,
5KSP51ECL552
1
R5422
0.30 230 C.C.W.
1550
2.83"
Hubless
G.E. 5422, 5KSP51ECL554
1
R5611
0.60 115 C.W.
1550
3.07"
Hubless
HUSSMANN 47000, 58698
1
R5612
0.60 115 C.C.W.
1550
3.07"
Hubless
HUSSMANN 38360
1
R6273
0.60 115 C.W.
1550
3.13"
Hubless
CONDENSER MOTOR FOR CAN TYPE VENDING
MACHINES
1
R5711
12
0.37 115 C.W.
1550
3.50"
Hubless
PSC,
HUSSMAN, HILL & KYSOR 400603, P41661,
19A10-055,
1
R5715
0.37 115 C.W.
1550
3.50"
Hubless
PSC,
TYLER & KYSOR 5215879, 5237801, 73049
1
R5720
0.37 115 REV.
1550
3.50"
Hubless
PSC,
HUSSMAN, HILL, TYLER & KYSOR 411151,
P23956, 5212930
1
Totally Enclosed - 3.5" Diameter (51 Frame)
Fig.1
Note: Motors may be converted to shaft
type by using shaft adapter #92-A8110
Domestic & Commercial Refrigeration
