Butt’s Pumps and Motors - page 1507

16
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from hub
face to shaft end
Motors
3.3" Motors
3.3" Motors
Permanent Split Capacitor
115 & 230 Volt - Sleeve Bearing & Ball Bearing
Part # Amps H.P. Volts Rot. Speed Const.
Shaft
Body Feature
Cap
Comment
Fig.
R371
0.38
1/20 230 C.W.
1/1550 OPEN 2.6"x5/16"
4.00 Plug, ball bearing INC.
Keeprite
1
R370
0.75
1/20 115 C.W.
1/1550 OPEN 2.8"x5/16"
4.00 Plug, ball bearing INC.
Keeprite
1
R373
0.90
1/15 115 C.C.W. 1/1400 T.E.
3.3"x3/8"
4.50
Plug
4/250 Greenhouse Fan 2
R499
1.00
1/15 115 C.C.W. 1/1625 OPEN 2.3"x5/16"
4.55 4studs front
4/370 Grainger 3M499B 3
R348
1.12
1/15 115 C.C.W. 2/1550 T.E.
3.4"x3/8"
4.1
3 ears
INC.
Vanee HRV M1703 4
R438
1.05
1/14 115 C.W.
2/1600 OPEN 1.5"x5/16"
4.25 3 Ears mtg.
4/370 Venmar HRV 01038 7
R462
1.10
1/17 115 C.C.W. 3/1660 OPEN 3.5"x3/8"x3.5"
4.00 2 studs side 7.5/370 Venmar HRV 02102 5
R312
1.20
1/12 115 C.C.W. 1/3250 OPEN 4.0"x5/16"
4.63
Internal Fan, ball
bearing
4/370
Engineered Air
101322
3
R701
1.30
1/12 115 C.C.W. 3/1550 T.E.
5.0"x5/16"x2.7" 4.60 4 studs front & rear INC.
Window A/C 6
R366
1.70
1/7 115 C.W 3/1630 OPEN 3.0"x3/8"x3.0"
4.75 2 studs side 7.5/370 Venmar HRV 02100 5
R422
2.90
1/6 115 C.W.
3/1690 OPEN 2.1"x3/8"
4.90
3 ears
7.5/370 Venmar HRV 02209 7
Fig.7
R422
R438
Fig.1
R370
R371
Fig.2
R373
Fig.3
R499
R312
Fig.4
R348
Fig.5
R366
R462
Fig.6
R701
