Motors
Flue Exhaust Motors
Flue Exhaust Motors
Fig. 1
RFM504
Fig. 5
RFM890
Fig. 6
RFM3
RFM4
RFM5
RFM653
Fig. 7
RFM580
Fig. 2
RFM461
Fig. 3
RFM2
RFM10
Fig. 4
RFM1198
Fig. 8
RFM11
Part # HP Spd/RPM Amps Volts Rot
Shaft
Body Type Mntg
Comment
Fig
RFM504
1/200
1/3000 0.25 208/230
C.C.W.
0.8"x1/4" 4.90
S.P.
4 LEG KEEPRITE 504015K
1
RFM461
1/40
1/3200 0.37 460
C.C.W.
2.5"x1/4" 5.80
S.P.
4 STUD
YORK 024-24115-019B
56" LEADS
2
RFM2
1/35
1/3000 1.30 115/230
C.C.W.
3.9"x5/16" 4.90
S.P.
2 STUD
FRANKLIN 80137,
FASCO D406, D408
3
RFM10
1/35
1/3000 1.30 115/230
C.W.
3.9"x5/16" 4.90
S.P.
2 STUD
E.J. WALSH 8211910172,
FEDDERS,W/CENTRIFUGAL
SWITCH
3
RFM1198
1/30
1/3200 1.50 115
C.W.
2.3"x5/16" 3.40
S.P.
LUGS
LENNOX 25J1201
4
RFM890
1/25
1/3200 0.70 208/230
CCW
2.3"x5/16" 3.29
S.P.
STUD LENNOX 98G8901, 7121-7091 5
RFM5
1/20
1/3000 1.80 115/230
C.C.W.
2.3"x1/4" 5.30
S.P.
4 STUD
FEDDERS S1900047003,
U.E. 570
6
RFM4
1/20
1/3000 1.80 115/230
C.W.
2.3"x1/4" 5.30
S.P.
4 STUD
CARRIER HC24AU700,
U.E. 571
6
RFM580*
1/20
1/3300 1.90 115
C.C.W.
1.9"x5/16" 3.50
S.P.
LUGS
HC27VE120, UNIV.
JA1P053N, BRYANT
P251-2307, U.E. 580
7
RFM11*
1/20
1/3200 1.80 115
C.C.W.
1.5"x5/16" 3.60
S.P.
3 LUGS CLARE BROS. M045
8
RFM653
1/20
1/3430 1.00 230/460
C.W.
2.1"x1/4" 5.90
S.P.
4 STUD
CARRIER, YORK, KEEPRITE
U653 FASCO 7131-0506,
5/16 BUSHING
6
RFM462
1/16
1/3450 0.30 460
C.W.
3.3"x5/16" 4.80
P.S.C.
/INC
4 STUD
ICP 1171347
CARRIER HC30GB460
9
RFM680
1/16
1/3450 1.00
115/208
/230
REV.
PLUG
1.2"x1/4" 7.00
P.S.C.
/INC
4 STUD
YORK 024-24115-001,701,
CARRIER HC680001B,
W/SWITCH
10
RFM3
1/16
1/3400 1.20 230/460
C.C.W.
2.3"x1/4" 6.20
S.P.
4 STUD
CARRIER, YORK, U660
W/CENT.SWITCH
5/16 BUSHING
6
RFM12*
1/15
1/3000 2.00 115
C.C.W.
1.3"x5/16" 4.40
S.P.
3 LUGS
M046 - CLARE
HIGH EFFICIENCY
11
* Note: Without Centrifugal Switch
Fig. 9
RFM462
Fig. 10
RFM680
Fig. 11
RFM12
