Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from hub
face to shaft end
Motors
5.5" Motors
5.5" Motors
Single Shaft - 208/230 Volts - Open
Part # HP Amps Spd/RPM Rot.
Body Shaft
Cap.
Bearing
Comment
Fig.
DD-046
1/2
3.80 4/1075
REV.
4.85 6.0"×1/2" 10/370
SLEEVE FM1056, D1735, 3788, R42449 1
DD-3588
1/2
3.60 3/1075
REV.
5.31 4.5"×1/2" 7.5/370
SLEEVE
D1056, WG840588, 1973, D703,
E206, 3588, X005, 528, R43588
3
R42487
1/2
3.40 3/1075
REV.PLUG
5.10 6.5"x1/2" 7.5/370
SLEEVE
FASCO D703, D841, U.E.149,
487, 528, MARATHON X005
3
R42784
1/2
2.80 3/1625
REV.PLUG
5.20 6.5"x1/2" 7.5/370
SLEEVE U.E.461, FASCO D784
1
R43601
1/2
2.80 4/1075
REV.PLUG
4.60 4.9"x1/2"
5/7.5/
10/370
SLEEVE
LENNOX 76N18, GE
MARS 03464R-R 51-23022-41,
EMERSON 5461
1
R32241
1/2
4.00 1/1075
REV.
7.70 4.5"x1/2"
INC.
BALL
DUNHAM BUSH MTR-226,
208/230/460 volts
5
R22017
1/2
4.00 1/1075
C.C.W.
7.40 4.5"x1/2" 7.5/370
SLEEVE
FASCO D804,
CARRIER HC44SL230
2
R32237
1/2
4.10 1/825
C.C.W.
5.80 2.7"x1/2" 12.5/370
BALL ARKLA B14506354, B14506396 2
R43588
1/2
4.30 3/1075
REV.
4.81 4.5"x1/2" 7.5/370
SLEEVE
GE 3588
3
R42008
1/2
4.50 1/1075
REV.PLUG
5.50 4.0"x1/2" 7.5/370
SLEEVE
HC43MZ228, EMERSON K940,
U.E. 445, G.E. KCP39NGD123T
3
R42249
1/2
4.90 3/1075
REV.PLUG
5.10 6.0"x1/2"
10/370
SLEEVE
GE 3788
1
R32184
1/2
5.10 3/1075
C.C.W.
5.30 3.5"x1/2"
10/370
SLEEVE
YORK 024-21671-000
3
R43241
1/2
4.40 3/1000
C.C.W.
5.10 3.9"x1/2" 7.5/370
SLEEVE
YORK 024-24106-000
6
Fig.1
R43601
R42784
Fig.2
R22017
R32237
R32184
Fig.3
R43132
R42008
R42487
DD-3588
Fig.4
R42249
DD-046
Sleeve & Ball Bearing - PSC
Fig.5
R32241
Fig.6
R43241
