Butt’s Pumps and Motors - page 1530

39
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from hub
face to shaft end www.rotom.ca
Motors
5.5" Motors
5.5" Motors
Part # HP Amps RPM Rot. Body Shaft Cap Bearing Comment Fig.
R22532 1/6 1.10 2/1075 REV.PLUG 3.70 6.5"x1/2" 5/370 SLEEVE GENERAL REPLACEMENT 3
R22648 1/6 1.30 2/825 REV.PLUG 4.50 6.5"x1/2" 5/370 SLEEVE KEEPRITE 171318, TRANE
WW94X296, YORK 24-21720-000 3
R31672 1/6 1.50 2/1050 C.W. 4.00 3.5"x1/2" 7.5/370 BALL KEEPRITE 171672, 120240
230 volts only 2
R22719 1/5 1.40 2/1075 REV.PLUG 3.70 5.5"x1/2" 5/370 SLEEVE U.E.442, FASCO D719 1
R32097 1/4 1.67 2/825 REV. 4.00 6.0"x1/2" 5/370 BALL GENERAL REPLACEMENT 2
R32702 1/4 1.80 2/1075 REV. 4.60 6.5"x1/2" 5/370 BALL GENERAL REPLACEMENT 3
R32739 1/4 1.98 2/1075 REV. 4.30 6.5"x1/2" 5/370 BALL FASCO D739 2
R22474 1/4 1.90 2/825 REV.PLUG 5.10 6.5"x1/2" 7.5/370 SLEEVE U.E.474 3
R32160 1/4 2.00 2/1075 C.W. 4.30 3.7"x1/2" 5/370 SLEEVE YORK 024-16076-700 4
R22475 1/3 2.50 2/825 REV.PLUG 5.60 6.5"x1/2" 12.5/370 SLEEVE U.E.475, FASCO D898 3
R32475 1/3 2.60 2/1075 REV. 4.80 6.5"x1/2" 7.5/370 BALL F1036, F45SN6V26,
323P199,323P946 2
R32476 1/3 2.60 2/825 REV. 5.30 6.5"x1/2" 7.5/370 BALL U.E. 476, FASCO D791, MARATHON
X086 2
R32703 1/3 2.60 2/1075 REV. 5.10 6.5"x1/2" 7.5/370 BALL GENERAL REPLACEMENT 2
R22746 1/3 2.60 2/1075 REV.PLUG 4.80 6.5"x1/2" 7.5/370 SLEEVE U.E.156, FASCO D746 3
R22748 1/3 2.60 2/1075 REV.PLUG 4.30 6.5"x1/2" 5/370 SLEEVE U.E.397, 501, FASCO D747,D748 3
R22444 1/3 2.80 2/1075 REV.PLUG 4.40 5.5"x1/2" 7.5/370 SLEEVE RHEEM-RUUD 512068801, 901,
512069001, U.E.444 1
R32477 1/2 3.40 2/825 REV. 5.50 6.5"x1/2" 10/370 BALL U.E. 477, FASCO D790 2
R32705 1/2 3.60 2/1075 REV. 1.00 6.5"x1/2" 10/370 BALL GENERAL REPLACEMENT 3
R32735 1/2 4.20 2/1075 REV. 5.10 6.5"x1/2" 10/370 BALL U.E. 157, FASCO D735 2
R22242 1/2 4.20 2/1075 REV.PLUG 5.10 6.5"x1/2" 10/370 SLEEVE U.E.499, CARRIER
HC43ME230HC43SZ230 2
R22745 1/2 4.40 2/1075 REV.PLUG 4.80 6.5"x1/2" 5/370 SLEEVE U.E. 445, 502, FASCO D745 3
R32706 3/4 4.20 2/1075 REV. 1.00 6.0"x1/2" 15/370 BALL GENERAL REPLACEMENT 3
R22755 3/4 5.00 2/1075 REV.PLUG 5.60 6.5"x1/2" 10/370 SLEEVE F48SQ6L66 3
R32730 3/4 5.10 2/1075 REV. 5.50 6.5"x1/2" 15/370 BALL MARATHON X085, X090, X095,
FASCO D930, U.E. 527 2
Single Shaft - 208/230 Volts - Semi-Enclosed
Sleeve & Ball Bearing - PSC
Fig.1
R22719
R22444
Fig.4
R32160
Fig.2
R22242
R31672
R32097
R32739
R32475
R32476
R32477
R32703
R32735
R32730
Fig.3
R22474
R22475
R22532
R22745
R22648
R22746
R22748
R32702
R32705
R32706
R22755
