Butt’s Pumps and Motors - page 1535

44
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from hub
face to shaft end www.rotom.ca
Motors
5.5" Motors
5.5" Motors
Single Shaft - 460 Volts
Sleeve & Ball Bearing - PSC - Open & Totally Enclose
Fig.1
R22275
R22139
R32957
R32512
Fig.2
R32422
R32400
R32718
R32716
Fig.6
R32241
Fig.3
R31712
R31718
Fig.5
R32420
R32423
R32421
R32424
Fig.4
R32714
R32712
R32710
Part # HP Amps Volt Spd/RPM Rot. Bearing Body Shaft Cap Encl. Comment Fig.
R31710 1/4 0.75 460 1/1075 REV.PLUG BALL 4.80 6.0"x1/2" 7.5/370 T.E.
CARRIER
HC39VE462,HC40GE460,
HC41AE460
3
R22275 1/4 0.80 460 1/850 C.W. SLEEVE 4.80 2.9"x1/2" 5/370 T.E. YORK 024-27501-000 1
R32420 1/4 1.00 460 1/1625 REV.PLUG BALL 4.00 6.0"x1/2" 5/370 S.E. FASCO D918, MARATHON
X420 5
R32423 1/4 1.00 460 1/1075 REV. BALL 4.30 6.0"x1/2" 5.0/370 T.E. GEN. REPLACEMENT 5
R32710 1/4 1.20 460 2/1625 REV. BALL 4.40 6.4"x1/2" 5/370 S.E. TRANE WW94X252,259,263,
418,TFM1864, R4111P517 4
R31712 1/3 0.90 460 1/1075 REV.PLUG BALL 5.30 6.0"x1/2" 7.5/370 T.E. CARRIER HC40MB549,
EMERSON 6523 3
R32714 1/3 10.00 460 1/825 REV. BALL 5.60 6.4"x1/2" 10/370 S.E. GENERAL REPLACEMENT 4
R32712 1/3 1.20 460 2/1075 REV. BALL 4.70 6.4"x1/2" 7.5/370 S.E.
HC39SE460,GE640,
5001P,5016T24-18412-003,
TRANE WW94X410
4
R32421 1/3 1.30 460 1/1625 REV.PLUG BALL 4.50 6.0"x1/2" 5/370 S.E. FASCO D916 5
R32424 1/3 1.40 460 1/1075 REV.PLUG BALL 4.80 6.0"x1/2" 7.5/370 S.E. FASCO D912MARATHON
X424 5
R31718 1/2 1.15 460 1/1050 REV.PLUG BALL 5.30 3.3"x1/2" 10/370 T.E. VERTICAL UP 3
R22139 1/2 1.30 460 1/1090 C.W. SLEEVE 5.00 3.4"x1/2" 7.5/370 T.E. YORK 024-24110-702 1
R32512 1/2 1.50 460 1/1100 C.C.W. BALL 8.30 4.8"x1/2" 5/440 OPEN
UE 151015, H3TO27,
02419512, 151015,
H3TO27141015
1
R32422 1/2 1.70 460 1/1625 REV.PLUG BALL 5.00 6.0"x1/2" 7.5/370 S.E. FASCO D916 2
R32400 1/2 1.80 460 1/1075 REV. BALL 1.00 6.0"x1/2" 10/370 T.E. VERTICAL UP 2
R32718 1/2 1.80 460 2/1625 REV. BALL 5.20 6.4"x1/2" 7.5/370 S.E. FASCO D916 2
R32716 1/2 1.90 460 2/1075 REV. BALL 5.50 6.4"x1/2" 10/370 S.E.
U.E.435,CARRIER,YORK,
TRANE WW94X315,
R4131P516
2
R32957 1/2 2.00 460 1/1075 C.C.W. BALL 7.50 4.3"x1/2" 5/370 OPEN YORK 024-183957-00 1
R32241 1/2 4.00 208/230/460 1/1075 REV. BALL 7.70 4.5"x1/2" INC. OPEN DUNHAM BUSH MTR-226 6
Motors continued next page
