41
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from hub
face to shaft end
Motors
5.5" Motors
5.5" Motors
Part # HP Amps Spd/RPM Rot.
Body Shaft
Cap Bearing
Comment
Fig.
R22601
1/3
1.90 2/825
REV.
4.80 5.0"x1/2" 10/370
BALL
MULTI HP 1/3 - 16
2
R22605
1/3
2.80 2/1075
REV.
4.80 6.0"x1/2" 7.5/370
BALL
MULTI HP 1/3 - 1/6
2
CF-3733
1/3
2.80 1/1075
REV.
5.15 6.5"×1/2" 7.5/370
BALL
FSE1036S, SV1, FE1036S, SB,
WG840729, 1861, 1877, D908,
D7908, 3733, 3729, E222, X413,
175, R31703
1
CF-813
1/3
1.90 1/825
REV.
5.00 6.5"×1/2" 7.5/370
BALL
FSE1038S, FE1038S, F1038,
1875, D936, D796, 791,D3026,
X451, X086, 475,740, 467,
R22345
1
R22345
1/3
2.40 1/825
REV.PLUG
5.50 6.0"x1/2" 7.5/370
SLEEVE GENERAL REPLACEMENT 1
R32556
1/3
2.60 2/1075
REV.PLUG
5.10 6.0"x1/2" 7.5/370
BALL
U.E.556, FASCO D731, D737,
KEEPRITE 121924, 161585
1
R22175
1/3
2.80 2/1075
REV.PLUG
5.00 6.0"x1/2" 7.5/370
SLEEVE
U.E. 175, 186
1
R22015
1/3
2.80 2/1075
REV.PLUG
4.80 6.0"x1/2" 7.5/370
SLEEVE
TRANE WW94X216, 256, 304,
305,325,WW94X335, 352, 354,
904
1
R31703
1/3
2.80 2/1075
REV.PLUG
5.10 6.0"x1/2" 7.5/370
BALL
GENERAL REPLACEMENT 1
R22603
1/2
2.40 2/825
REV.
4.80 6.0"x1/2" 12.5/370
BALL
MULTI HP 1/2 - 1/5
2
R22245
1/2
3.70 1/825
REV.PLUG
5.60 6.0"x1/2" 10/370
SLEEVE
FSE1058S, F48SR8L3
1
R22602
1/2
3.90 2/1075
REV.
4.80 5.0"x1/2" 12.5/370
BALL
GENERAL REPLACEMENT 2
CF-3734
1/2
3.50 1/1075
REV.
5.58 6.5"×1/2" 10/370
BALL
FSE1056S, SV1, FE1056S,SB,
WG840730, 1862, 1878, D907,
D7907, E223, 3730, 3734, X414,
187, 5578, R31705
1
R22140
1/2
2.70 2/1090
C.W.
5.00 3.4"x1/2" 7.5/370
SLEEVE
YORK 024-24110-701
3
R31705
1/2
3.50 2/1075
REV.PLUG
1.00 6.0"x1/2" 10/370
BALL
GENERAL REPLACEMENT 1
R22016
1/2
4.00 2/1075
REV.PLUG
5.20 6.0"x1/2" 10/370
SLEEVE
FASCO D717, YORK 24-17420-
00024-70797-000,
TRANE WW94X303,343
1
R22187
1/2
4.00 2/1075
REV.PLUG
5.20 6.0"x1/2" 10/370
SLEEVE U.E. 187, FASCO D740
1
R32557
1/2
4.20 2/1075
REV.PLUG
5.50 6.0"x1/2" 10/370
BALL KEEPRITE 155483, U.E. 557 1
R22460
1/2
4.20 2/1625
REV.PLUG
5.60 6.0"x1/2" 5/370
SLEEVE GENERAL REPLACEMENT 1
R22604
3/4
5.30 2/1075
REV.
4.80 6.0"x1/2" 15/370
BALL
MULTI HP 3/4 - 1/4
2
CF-3735
3/4
5.10 1/1075
REV.
5.88 6.5"×1/2" 15/370
BALL
FSE1076S,SV1, FE1076, 1868,
1879, D931, 3731, 3735, X095,
779, 668, R31706
1
R31706
3/4
4.70 2/1075
REV.PLUG
5.60 6.5"x1/2" 12.5/370
BALL
GENERAL REPLACEMENT 1
R22168
3/4
5.20 2/1075
REV.PLUG
5.60 6.5"x1/2" 15/370
SLEEVE GENERAL REPLACEMENT 1
R22175
R22015
R31703
R31705
R22345
R22016
R22187
R22460
R31706
R32556
R32557
R22168
R22245
CF-3733
CF-813
CF-3734
CF-3735
Fig.1
Fig.2
R22601
R22602
R22603
R22604
R22605
Fig.3
R22140
Single Shaft - 208/230 Volts -Totally Enclosed
Sleeve & Ball Bearing - PSC
Motors continued from previous
