45
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from hub
face to shaft end
Motors
5.5" Motors
5.5" Motors
Fig.1
R32720
R32426
R31717
R31716
R30575
R34201
R42606
R42607
Fig.2
R32671
R32053
R42604
R42605
Fig.4
R43460
Fig.3
R32051
R32050
Fig.7
R31065
R42575
Sleeve & Ball Bearing - PSC - Open & Totally Enclosed
Single Shaft - 460 Volts
Fig.5
R42141
Fig.6
R43520
R42850
Part # HP Amps Volt
Spd/RPM Rot.
Bearing Body Shaft
Cap Encl.
Comment
Fig.
R31717
3/4
1.90 460 2/1075
REV.PLUG BALL
6.10 6.0"x1/2" 10/370
T.E.
ALL ANGLE CARRIER 1
R32671
3/4
2.10 460 3/1050
C.C.W.
BALL
5.30 4.0"x1/2" 12.5/370
OPEN YORK 024-21671-000 2
R32051
3/4
2.15 460 3/1075
REV.PLUG BALL
6.63 4.0"x1/2" 15/370
OPEN
YORK, THERMOPLUS,
LENNOX, CARRIER
3
R32720
3/4
2.20 460 2/1075
REV.
BALL
5.50 6.4"x1/2" 15/370
S.E.
CARRIER HC45MF460,
U.E.158,FASCO D704,
1
R32426
3/4
2.20 460 1/1075
REV.
BALL
5.50 4.5"x5/8" 7.5/370
OPEN VERTICAL UP
1
R31716
3/4
2.50 460 1/1075
REV.PLUG BALL
6.10 6.0"x1/2" 10/370
T.E.
FASCO D1914,
MARATHON X099
1
R43520
3/4
2.00 460 3/1075
C.C.W BALL
6.00 2.5"x1/2" 20/370
OPEN LENNOX 43G5201
6
R43460
1
2.50 460 3/1100
C.C.W.
BALL
6.50 4.0"x1/2" 25/370
OPEN YORK 0242500001
4
R32053
1
3.00 460 3/1100
C.C.W.
BALL
7.00 4.0"x1/2" 25/370
OPEN YORK 024-25000D004-001 2
R42850
1
3.20 460 3/1100
REV.PLUG BALL
6.10 4.5"x1/2" 15/370
OPEN GENERAL REPLACEMENT 6
R42141
1
7.60
208/230/460
1/1075
REV.
BALL
8.50 4.0"x1/2" INC.
OPEN KRAMER DD661, DD791 5
Part # HP Amps Volt
Spd/RPM Rot.
Bearing Body Shaft
Cap Encl.
Comment
Fig.
R30575
1/6
0.50 575 1/1625
REV.
SLEEVE
4.50 2.2"x1/2" INC.
OPEN
MARATHON
A48170246A,HUSSMAN
077228, CMS 30575
1
R34201
1/5
0.50 575 1/1075
C.W.
SLEEVE
4.50 2.5"x1/2" INC.
OPEN
UE HA3J010, HA3J036,
HUSSMAN 204201, CMS
30125
1
R31065
1/4
0.50 575 1/1140
REV.
BALL
6.30 2.8"x5/8"
-
T.E.
KEEPRITE 171065,
U.E. HM3G004K
7
R42604
1/3
1.50 575 1/1100
REV.PLUG BALL
5.80 6.0"x1/2" 7.5/440
T.E.
TRANE MOT2604,
LENNOX 25G20
2
R42605
1/2
1.00 575 1/1625
REV.PLUG BALL
5.60 6.0"x1/2" 7.5/440
T.E.
TRANE M02605, CENTURY
173329MAGNETEK HF2J043
2
R42575
1/2
1.80 575 1/1140
REV.
BALL
7.90 2.5"x1/2" 7.5/440
S.E.
CARRIER HD44ML461,AO
SMITH P48J6A2
7
R42606
1/2
1.20 575 1/1100
REV.PLUG BALL
5.50 6.0"x1/2" 7.5/370
T.E.
TRANE, COMFORTAIRE 1
R32050
3/4
1.65 575 3/1024
REV.PLUG BALL
6.50 4.0"x1/2" 15/370
OPEN
YORK, THERMOPLUS,
LENNOX, CARRIER
3
R42607
3/4
1.90 575 1/1075
REV.PLUG BALL
6.00 6.0"x1/2" 15/370
T.E.
CENTURY HM3T071,
TRANE,MOT2607,
MARATHON 48A11T566
1
Single Shaft 575 Volts
Motors continued from previous
