Butt’s Pumps and Motors - page 1580

89
Rotation determined opposite shaft end
Double shaft determined at lead end
Shaft length measured from
hub face to shaft end
OEM
OEM Replacement Motors
OEM Replacement Motors
Climate Master
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
T2541
1
1/1140
575
1.70
Rev
SP 6.5"
8.22"
5.0"×5/8"
5J999GBX, 56T105308 8
Clare Brothers
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
RFM11
1/20
1/3200
115
3.00 CCW
3.3"
3.6"
1.5"×5/16"
M045, High Efficiency 1
RFM12
1/15
1/3100
115
3.00 CCW
3.3"
5.8"
2.0"×5/16"
M046
2
RFB17
1/15
1/3100
115
2.00 CCW
3.3"
-
-
V17, V10, V25
3
Clawsey - Sohrt
Climetec
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R404
1/50
1/1550
115
0.85 CCW SP 3.3"
2.84"
1.8"×5/16"
Space Heater
4
Part # HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R2198
1/14
3/820
115
1.30 CCW
7.5/370
5.0"
4.50"
3.4×1/2"
C/W Plug
5
R2197
1/14
3/820
115
1.30 CCW
7.5/370
5.0"
4.50"
3.4"×1/2"
C/W Plug, 8.37" bolt circle 6
DD-029
1/8
5/1000
115
2.10
Rev PSC/INC 5.5"
3.61"
5.0"×1/2"
L350, L450, L600,
DA3E200, DA3F100,
DA3G142, R2299
7
Fig.1
Fig.5
Fig.4
Fig.2
Fig.6
Fig.3
Fig.7
Fig.8
