OEM Replacement Motors
OEM Replacement Motors
E.K.W.
(Electrohome - Keeprite - Woods)
Part #
HP Spd/RPM Volts Amps Rot
Type Dia Body
Shaft
Comment
Fig
R506
1/240
1/1400
115
0.43
CW SP 3.3"
1.90"
2.0"×1/4"
2N8701
2
R503
1/130
1/1550
115
0.40
CW SP 3.3"
2.09"
2.4"×1/4"
SN4702
2
R325
1/125
1/1550
115
0.33 CCW SP 3.3"
2.09"
2.3"×1/4"
2N8001
3
R235
1/80
1/1050
115
0.90 CCW SP 3.3"
2.35"
1.1"×1/4"
W.C. Woods
3
R512
1/75
1/1550
115
0.62
CW SP 3.3"
2.09"
1.0"×1/4"
2N10201
2
R201
1/50
1/1430
115
0.85
CW SP 3.3"
2.20"
2.3"×1/4"
Humidifiers
2
R236
1/50
2/1575
115
1.00 CCW SP 3.3"
2.25"
1.1"×1/4"
27009909, 471628009 4
R510
1/45
3/1550
115
1.10
CW SP 3.3"
2.25" 1.1"×1/4"×1.5"
W.C. Woods
3
R336
1/25
1/1550
115
1.50 CCW SP 3.3"
2.60"
1.2"×1/ 4"
W.C. Woods
5
R717
1/15
3/1550
115
2.00 CCW SP 3.3"
3.50" 5.0"×5/16"×3.5"
SM717
3
R729
1/15
3/1550
115
2.00 CCW SP 3.3"
3.50" 3.5"×5/16"×5.0"
SM704
6
R731
1/15
2/1550
115
2.35 CCW
SP
4.1"
3.10" 2.3"×3/8"×2.3"
SM703
7
R736
1/12
3/1080
115
3.50 CCW
4/370
5.0"
3.50" 1.9"×1/2"×2.7"
SM701, 715, 706, 716,
721
7
R780
1/8
3/1330
115
1.70 CCW
10/370
5.0"
3.50" 2.4"×1/2"×5.0"
89395, 200423, SM713 7
T2538
1
1/1140
208/230
460
4.20
Rev
3 PH
6.5"
9.10"
5.0"×5/8"
170518, 502595
8
T2540
1
1/1140
575
1.20
Rev
3 PH
6.5"
9.10"
5.0"×5/8"
170517, KPN502597 8
Fig. 1
Fig. 3
Fig. 4
Fig.6
Fig. 5
Fig. 2
Fig.7
Fig.8
Duotherm
Part # HP Spd/RPM Volts Amps Type Rot
Dia Body
Shaft
Comment
Fig
R404
1/50
1/1550
115
0.85
SP CCW 3.3"
2.84"
1.8"×5/16"
Space Heater
1
