Full
F.L.
Gearmotor
Arm
Load
Input Torque Output
Catalogue
Type &
Ratio
Volts
Amps.
HP (In.-Lbs.) RPM
Number
Enclosure
Frame
to 1
DC
DC
1/8
* 125
28
M1135292
TENV
12B60-34D
61
90
1.6
1/8
*
87
45
M1135291
TENV
12B39-34D
39
90
1.6
1/4
158
58
M1135290
TEFC
12B30-34G
30
90
2.8
1/4
100
90
M1135289
TEFC
12B19-34G
19
90
2.6
1/4
85
115
M1135288
TEFC
12B15-34G
15
90
2.6
1/4
61
167
M1135287
TEFC
12B11-34G 10.6
90
2.6
1/4
46
250
M1135286
TEFC
12B7-34G
7
90
2.6
* Supplied with TENV motor enclosure
, / Ê ÊUÊ "7Ê6" / Ê£Ó6®
/ 6ÊUÊ£°äÊ- ,6 Ê
/",
Full
F.L.
Gearmotor
Arm
Load
Input Torque Output
Catalogue
Type &
Ratio
Volts
Amps.
HP (In.-Lbs.) RPM
Number
Enclosure
Frame
to 1
DC
DC
1/8
134
27
M1135285
TENV
12B60-34C
61
12
14
1/8
94
45
M1135284
TENV
12B39-34C
39
12
15
1/4
158
58
M1135297
TENV
12B30-34F
30
12
24
1/4
100
90
M1135296
TENV
12B19-34F
19
12
24
1/4
85
115
M1135295
TENV
12B15-34F
15
12
23
1/4
61
167
M1135294
TENV
12B11-34F 10.6
12
21
1/4
46
250
M1135293
TENV
12B7-34F
7
12
23
SERIES 12 SUB-FHP
RIGHT ANGLE DC GEARMOTORS
NOTES:
1. Conduit box not supplied with the gearmotor. Mounting provisions are provided and can use conduit
box kit catalogue number M1760007 found on page 121.
2. For solid double output shaft, consult factory.
SERIES 12 SUB-FHP
Electrical Specifications:
Both SCR (90 volt)
and Low Voltage
(12 volt) right angle
gearmotors. the
90 volt motors
are performance
matched for
continuous service
over a 60:1 speed
range. All have constant
torque throughout the speed range when powered by a full-wave,
unfiltered SCR-type 115 volt input adjustable speed control having
a typical form factor of 1.3 to 1.4. The low voltage motors are also
performance matched for continuous duty. Motors are designed for
battery power or can be used with a low voltage controller with form
factor up to 1.05.
Mechanical Specifications:
This worm-type right-
angle gearing features
hardened, steel worm
with bronze worm wheel
for long life and quiet
operation. Single-piece
die cast aluminum alloy
housing is vacuum
impregnated with Resinol
RT for protection and
sealing. This gearbox combines
light weight with high tensile strength
along with being precision machined for alignment of bearings and
gearing. For optimum seal life, we use high-temperature Nitrile seals.
Gearbox provided with solid output shaft, but can be converted to a
hollow output shaft mounting by using snap-ring pliers and remove
the snap ring and solid output shaft. Also the T-base feet are bolted
to the gearbox, but can easily be removed and converted to face
mounting.
