13
Refrigeration
Single Phase - 208/230 Volt (R22)
Part #
@45°F/130°F Evap @45°F/110°F Evap
HZ RLA LRA MCC Dis Suc
Oil
Chrg
(oz)
Dimensions (") Weight
(Lbs.)
BTUH EER BTUH EER
A B C
H24B13QABCA
12600 8.0
15476 11.1 50/60 8.6 40 13.0 5/16 E 1/2 E 40 10.5 12.2 12.5 53.5
H24B13QABCB
12600 8.0
15476 11.1 50/60 8.6 40 13.0 5/16 E 1/2 E 40 10.5 12.2 12.5 53.5
H23B15QABCB
14900 9.8
18117 13.4 50/60 6.7 45 14.0 3/8 E 5/8 E 40 12.2 12.6 12.9 62.0
H29B15UABCA
15700 10.6 19602 14.8 50/60 6.7 48 12.0 3/8 E 5/8S 35 11.2 13.2 13.5 64.0
H23B17QABCB
16600 9.8
19994 13.4 50/60 7.6 54 15.0 3/8 E 5/8 E 40 12.2 12.6 12.9 63.5
H29B17UABCA
17200 10.7 21455 14.9 50/60 7.2 48 14.0 3/8 E 5/8 S 35 11.2 13.2 13.5 64.0
H23B19QABCB
17900 9.8
21711 13.6 50/60 8.2 57 16.0 3/8 E 5/8 E 40 12.8 13.2 13.5 65.0
H29B18UABCA
18100 10.8 22336 15.0 50/60 7.4 48 14.0 3/8 E 5/8 S 35 11.2 13.2 13.5 64.0
H29B20UABCA
20400 10.7 24757 14.6 50/60 8.6 60 17.0 3/8 E 5/8 S 35 11.2 13.2 13.5 64.0
H23B22QABCB
21800 9.8
26542 13.4 50/60 9.7 57 18.8 3/8 E 5/8 E 40 12.8 13.2 13.5 65.5
H29B22UABCA
22500 10.7 27381 14.7 50/60 9.6 60 18.0 3/8 E 5/8 S 35 11.2 13.2 13.5 66.0
H23B24QABCB
24000 9.8
28059 13.1 50/60 10.9 66 20.2 3/8 E 5/8 E 40 12.8 13.2 13.5 66.0
H29B24UABCA
24200 10.9 29080 15.1 50/60 9.6 61 19.0 1/2 E 3/4 S 35 11.7 13.8 14.0 68.5
H29B26UABCA
26500 10.9 31542 15.1 50/60 10.9 68 20.0 1/2 E 3/4 S 35 11.7 13.8 14.0 68.5
H23B28QABCB
27800 9.7
32706 12.9 50/60 12.8 76 23.0 3/8 E 5/8 E 40 12.8 13.2 13.5 67.5
H29B28UABCA
28200 10.9 33579 14.9 50/60 11.8 73 22.0 1/2 E 3/4 S 35 11.7 13.8 14.0 68.5
H29B30UABCA
29800 11.0 35420 15.0 50/60 12.4 82 23.0 1/2 E 3/4 S 35 12.2 14.2 14.5 73.0
H29B32UABCA
31800 10.9 37984 15.0 50/60 13.0 82 23.5 1/2 E 3/4 S 35 12.2 14.2 14.5 73.0
H29B35UABCA
35300 10.9 41718 14.9 50/60 14.4 86 26.0 1/2 E 3/4 S 40 12.2 14.2 14.5 75.0
H23A383ABCA
37900 10.3 45130 14.0 50/60 17.0 97 30.0 3/8 E 3/4 E 50 12.0 14.6 14.9 82.5
H23A423ABCA
42100 10.4 49820 14.0 50/60 18.7 110 31.2 1/2 E 7/8 E 50 12.5 14.6 14.9 82.5
H23A463ABCA
46300 10.3 54570 13.4 50/60 21.6 118 36.4 1/2 E 7/8 E 55 12.5 14.6 14.9 85.5
H23A503ABCA
49000 10.0 59189 13.7 50/60 22.3 138 40.0 1/2 E 7/8 E 55 14.0 16.1 16.4 92.0
H23A543ABCA
53400 10.0 63061 13.0 50/60 24.4 138 45.5 1/2 E 7/8 E 55 14.0 16.1 16.4 95.5
H23A563ABCA
55600 10.1 66028 13.2 50/60 24.6 142 45.0 1/2 E 7/8 E 55 14.0 16.1 16.4 95.5
H23A623ABCA
60800 10.0 71127 13.0 50/60 28.2 78 47.0 1/2 E 7/8 E 55 14.0 16.1 16.4 97.5
* Requires Motor Protection Part Numbers Ending In “R” = Rotolock Unless Otherwise Indicated All Compressors Are Sweat
R22 Reciprocating Compressors - Single Speed
H29B
H23A & H23B
H24B
Air Conditioning
Compressors
