19
Refrigeration
Low Temp Single & Three Phase - 120, 208/230 & 460 Volt (R404A)
Part #
HP BTUH Watt BTUH Watt
Volt Ph HZ Dis Suc Pro.
Dimensions (")
L63B562BBAB
1 5350 1568 3425 1003 120 1 60 3/8 5/8 3/8 12.91 9.75 7.25
L63B562BBCB
1 5350 1568 3425 1003 208/230 1 60 3/8 5/8 3/8 12.91 9.75 7.25
L63B562DBD
1 5350 1568 3425 1003 208/230 3 60 3/8 5/8 3/8 12.91 9.75 7.25
L63B562DBEB
1 5350 1568 3425 1003 460 3 60 3/8 5/8 3/8 12.91 9.75 7.25
L63B652BBCB
11⁄4 6200 1817 3970 1163 208/230 1 60 3/8 5/8 3/8 13.53 9.75 7.25
L63B652DBDB
11⁄4 6200 1817 3970 1163 208/230 3 60 3/8 5/8 3/8 12.91 9.75 7.25
L63B652DBEB
11⁄4 6200 1817 3970 1163 460 3 60 3/8 5/8 3/8 12.91 9.75 7.25
L63B752BBCB
11⁄2 7600 2227 4850 1421 208/230 1 60 3/8 5/8 3/8 13.53 9.75 7.25
L63B752DBDB
11⁄2 7600 2227 4850 1421 208/230 3 60 3/8 5/8 3/8 12.91 9.75 7.25
L63B752DBEB
11⁄2 7600 2227 4850 1421 460 3 60 3/8 5/8 3/8 12.91 9.75 7.25
L63A113BBCA
2 10700 3135 7698 2256 208/230 1 60 1/2 3/4 3/8 14.91 10.25 8.125
L63A113DBLA
2 10800 3165 7310 2142 208/230 3 60 1/2 3/4 3/8 14.91 10.25 8.125
L63A113DBEA
2 10800 3165 7310 2142 460 3 60 1/2 3/4 3/8 14.91 10.25 8.125
L63A183BBCA
3 18100 5304 13316 3902 208/230 1 60 1/2 3/4 3/8 14.91 10.25 8.125
L63A183DBDA
3 18000 5274 13647 3999 208/230 3 60 1/2 3/4 3/8 14.91 10.25 8.125
L63A183DBEA
3 18000 5274 13647 3999 460 3 60 1/2 3/4 3/8 14.91 10.25 8.125
Medium Temp Single & Three Phase - 208/230, 460 & 575 Volt (R404A)
Part #
HP BTUH Watt BTUH Watt
Volts Ph HZ Dis Suc Pro.
Dimensions (")
M63B872BBCB
1 8700 2549 7350 2174 208/230 1 60 3/8 5/8 3/8 12.91 9.75 7.25
M63B982BBCB
1 9500 2783 7716 2261 208/230 1 60 3/8 5/8 3/8 12.91 9.75 7.25
M63B123DBDB
11⁄2 12000 3516 10200 2989 208/230 3 60 3/8 5/8 3/8 12.91 9.75 7.25
M63B123BBCB
11⁄2 12000 3516 10200 2989 208/230 1 60 3/8 5/8 3/8 13.53 9.75 7.25
M63B153BBCB
2 15000 4395 12700 3721 208/230 1 60 3/8 5/8 3/8 13.53 9.75 7.25
M63B153DBEB
2 15000 4395 12700 3721 460 3 60 3/8 5/8 3/8 13.53 9.75 7.25
M63B153DBLB
2 15000 4395 12700 3721 208/230 3 60 3/8 5/8 3/8 13.53 9.75 7.25
M63B203BBCB
21⁄4 19600 5743 15903 4660 208/230 1 60 3/8 5/8 3/8 13.53 9.75 7.25
M63B203DBDB
21⁄4 19200 5626 15991 4686 208/230 3 60 3/8 5/8 3/8 13.53 9.75 7.25
M63A243BBCA
21⁄2 24000 7033 20375 5970 208/230 1 60 1/2 3/4 3/8 14.91 10.25 8.125
M63A243DBDA
21⁄2 24000 7033 20375 5970 208/230 3 60 1/2 3/4 3/8 14.91 10.25 8.125
M63A243DBEA
21⁄2 24000 7033 20375 5970 460 3 60 1/2 3/4 3/8 14.91 10.25 8.125
M63A273BBCA
3 27000 7912 22900 6710 208/230 1 60 1/2 3/4 3/8 14.91 10.25 8.125
M63A273DBDA
3 27000 7912 22900 6710 208/230 3 60 1/2 3/4 3/8 14.91 10.25 8.125
M63A273DBEA
3 27000 7912 22900 6710 460 3 60 1/2 3/4 3/8 14.91 10.25 8.125
M63A273DBFA
3 27000 7912 22900 6710 575 3 60 1/2 3/4 3/8 14.91 10.25 8.125
M63A323BBCA
31⁄2 32000 9377 27150 7956 208/230 1 60 1/2 3/4 3/8 16.41 10.25 8.125
M63A323DBDA
31⁄2 32000 9377 27150 7956 208/230 3 60 1/2 3/4 3/8 16.41 10.25 8.125
M63A323DBEA
31⁄2 32000 9377 27150 7656 460 3 60 1/2 3/4 3/8 16.41 10.25 8.125
R404A Reciprocating Compressors - Single Speed
Commercial
Refrigeration
Applications
Rating Conditions
LBP ASHRAE ARI
Evaporator
-10°F -10°F
Condenser 130°F 120°F
Ambient
90°F 95°F
Liquid
90°F 120°F
Return Gas 90°F 40°F
Rating Conditions
MBP ASHRAE ARI
Evaporator
20°F 20°F
Condenser 130°F 120°F
Ambient
95°F 95°F
Liquid
115°F 120°F
Return Gas 95°F 40°F
M63B153BBCA
Medium Temp Compressor
L63A113BBCA
Low Temp Compressor
A Series
B Series
Compressors
Note:
Series type is
determined by
last letter in
Part #.
