Butt’s Pumps and Motors - page 1027

22 Refrigeration www.alltemp.ca
Two Door Refrigerator Compressor Selection
Fibreglass Insulation
Freezer Compressor Selection
Foam Insulation
No Frost Side By Side - Coil and blower are hidden.
• Fibreglass insulation.
Embraco Part # Reference
30-FF11.5BKW Up to 20 cubic feet.
30-FFI12BKW 20 to 25 cubic feet.
No Frost Top Mount - Coil and blower are hidden.
• Fibreglass insulation.
Embraco Part # Reference
30-FF6BK or FF8.5BKW Up to 14 cubic feet.
30-FF8.5BKW 14 to 17 cubic feet.
30-FF11.5BKW Over 17 cubic feet.
No Frost Top Mount
• Fibreglass insulation.
• Two doors with separate evaporator coils (plates) in the freezer and in the
refrigerator compartments.
• Freezer space separated by solid partition from refrigerator space.
• Semi-automatic (manual start, automatic stop) defrost or fully automatic.
Embraco Part # Reference
30-FF6BKW Up to 12 cubic feet.
30-FF8.5BKW 12 to 14 cubic feet.
30-FF8.5BKW 14 to 16 cubic feet.
30-FF11.5BKW Over 16 cubic feet.
Freezers
Embraco Part # Reference
30-PW4.5K9 Up to 10 cubic feet.
30-FF6BKW 10 to 13 cubic feet.
30-FF6BK or FF8.5BKW 13 to 16 cubic feet.
30-FF11.5BKW Over 17 cubic feet.
Freezers - Vertical Visible Frost
Embraco Part # Reference
30-PW4.5K9 Up to 10 cubic feet.
30-FF6BKW 10 to 13 cubic feet.
30-FF8.5BKW 13 to 16 cubic feet.
30-FF11.5BKW Over 17 cubic feet.
30-FF8.5BKW Up to 16 cubic feet.
30-FF11.5BKW Over 16 cubic feet.
Fibreglass Insulation
Fibreglass Insulation
Foam Insulation
Compressors
