Refrigeration
Embraco Nomenclature
Compressor Nomenclature
F Series Compressor Nomenclature
Efficiency Level
NIHIL
- Standard Efficiency.
E
- Improved 1st generation.
I
- Improved 2nd generation.
V
- Improved 3rd generation.
S
- Improved 4th generation.
T
- Improved 5th generation.
Refrigerant
H
- R134a
NIHIL
- R12
Application
A
- LBP
B
- HBP,
LBP/HD
H
- HBP
Starting
Characteristics
NIHIL
- LST Improved
Efficiency.
K
- LST.
X
- HST.
Compressor
Cooling
NIHIL
- Without Oil
Cooler.
W
- With Oil
Cooler.
30 - F G S 60 H A K W
F
Basic
Type
Electrical System
F
- Relay / external proctor.
- Relay / externalproctor /
start capacitor (optional).
G
- PTC / external proctor.
- PTC / external proctor
/ start cap / run cap
(optional).
T
- PTC / external
proctor / run capacitor
(mandatory).
Approx.
Compressor
Displacement
(For FG
compressors
approximate
capacity in
BTUH - 60Hz
- check point
divided by 10).
30
Product
Category
PW Series Compressor Nomenclature
Maximum
Rated Motor
Torque
Refrigerant
H
- R134a
NIHIL
- R12
Motor Type
K
- Standard
efficiency.
A
- High
efficiency
Compressor
Cooling
NIHIL
- Without Oil
Cooler.
W
- With Oil
Cooler.
30 - PW 5.5 H K 14 W
PW
Basic
Type
Compressor
Rated
Displacement
30
Product
Category
EM Series Compressor Nomenclature
Compressor
Capacity
Capacity in BTUH
- 60Hz - check point
divided by 10.
Refrigerant
H
- R134a
C
- R600a
NIHIL
- R12.
Electrical Equipment
P
- PTC + run cap
(optional).
R
- Relay.
C
- PTC + run cap
(mandatory).
S
- PTC + run & start
cap.
V
- PTC + run & start
cap (optional).
30 - EM I 60 H N R
Basic Type
EM
Embraco mini
compressor
30
Product
Category
Valve
System
I
- New
NIHIL
- Standard
Efficiency Level & Application
N
- Standard LBP.
J
- Intermediate LBP.
E
- Improved 1st generation LBP.
S
-Improved 2nd generation LBP.
H
- L/M/HBP applications.
D
- HBP applications.
B
- M/HBP applications. ( L/M/
HBP for R12 compressors)
EM Series Compressor Nomenclature
30 - EM S 36 H L P
Compressor Capacity
Rated cooling capacity
divided by 10 expressed
in BTUH (subcooled liquid
conditions) and referredto
the frequency listed on the
compressor nameplate.
Refrigerant
Blank
- R12.
H
- R134a
C
- R600a
Electrical Equipment
P
- PTC + run cap (optional).
R
- Relay.
C
- PTC + run cap (mandatory).
X
- Relay + mandatory start
cap.
Basic Type
EM
Embraco mini
compressor
30
Product
Category
Efficiency Level
S
- Standard.
T
- 1st generation.
U
- 2nd generation.
Y
- 3rd generation.
Z
- 4th generation.
Application
L
- LBP.
H
- HBP.
Compressors
