Single Door Refrigerator Compressor Selection
Foam Insulation
Two Door Refrigerator Compressor Selection
Foam Insulation
Foam Insulation - Automatic Defrost
Conventional - Gravity flow from freezer.
• Foam Insulation.
• Conventional - Single Door (sometimes 2 doors)
• Frozen food space is closed by interior door
• Refrigerator space is cooled by gravity air flow from the
evaporator coil.
Embraco Part # Reference
30-PW4.5K9 Up to 13 cubic feet.
30-FF6BKW 13 to 15 cubic feet.
30-FF8.5BKW Over 15 cubic feet.
Two Temperature
• Foam Insulation.
• Two doors with separate evaporator coils (plates) in the freezer and in the
refrigerator compartments.
• Freezer space separated by solid partition from refrigerator space.
• Semi-automatic (manual start, automatic stop) defrost or fully automatic.
Embraco Part # Reference
30-PW4.5K9 Up to 13 cubic feet.
30-FF6BKW 13 to 15 cubic feet.
30-FF8.5BKW Over 15 cubic feet.
No Frost Top Mount - Coil and blower are hidden.
• Foam Insulation.
• Automatic defrost.
Embraco Part # Reference
30-FF6BKW Up to 14 cubic feet.
30-FF8.5BKW 14 to 17 cubic feet.
30-FF8.5BKW 17 to 20 cubic feet.
30-FF11.5BKW Over 20 cubic feet.
No Frost Side By Side - Coil and blower are hidden.
• Foam Insulation.
• Automatic defrost.
Embraco Part # Reference
30-FF8.5BKW Up to 18 cubic feet.
30-FF11.5BKW 18 to 25 cubic feet.
30-FFI12BKW Over 25 cubic feet.
Foam Insulation - Automatic Defrost
Compressors
