Refrigeration
Core Depressors
Core Depressors
Part #
Description
02-CD2060
For 1/4" male flares.
02-CD2050
For 3/16" male flares.
02-CD2070
For 1/4" male flares. Depresses
valve core and controls flow. Back
seats and retains gas in the hose.
02-CD5050
For 1/4" male flares. Small design
makes this service tool ideal in
small quarters.
Core Depressors
These thumbscrew core depressors are designed to be used on the
end of a charging hose. When attached to an access fitting, they can
depress the valve core and control the flow of gas. This also means
the core can be shut off before disconnecting, thus avoiding a split
back on your hand. The seals in each part have broad compatibility
with the newer refrigerants. The 02-CD2070 is unique in that it has an
internal shut-off that also holds gas in the hose when disconnected.
02-CD2060 & 02-CD2050
Illustrated
02-CD2070
Illustrated
02-CD5050
Illustrated
Core Depressors - Ball Valve Hose End
Ball Valve Hose-End
Reliable and easy to use. The body of this valve is constructed with
the same durable design as the BV series service tools (CRT). Install
the 02-CD4040 on the end of a charging hose and minimize refrigerant
loss during service. A quarter turn of the handle makes quick work
of shutting on or off the valve. Straight flow through design offers
maximum flow rate. The brass depressor tip fully engages valve core.
02-CD4040
Illustrated
Ball Valve Hose -End
Part #
Description
02-CD4040
1/4" female flare swivel, depressor tip ×
1/4" male flare.
Core Depressors - Retaining Couplers - "Sure Seal"
Sure Seal - Retaining Couplers
When attached to an access fitting, the "Sure Seal" retaining coupler
automatically open and depresses the valve core all in one action.
When disconnected, it traps refrigerant in the charging hose. Leave
it permanently installed on the end of the hose. The seals are
compatible with newer refrigerants, and if internal parts need replacing,
a parts kit (02-CD5171) is available.
02-CD2035
Illustrated
"Sure Seal" - Retaining Couplers
Part #
Description
02-CD2035
1/4" female flare retainer × 1/4" male flare.
02-CD2090
90° 1/4" female flare retainer × 1/4" male flare.
02-CD2037
1/4" female flare retainer × 3/8" male flare.
02-CD2094
1/4" female flare retainer × 1/4" FPT.
02-CD2098
1/4" female flare retainer × 1/8" FPT.
02-CD2084
1/4" female flare retainer × 1/4" MPT.
Repair Kit (02-CD5171 - includes seals, depressor & spring)
02-CD2090
Illustrated
02-CD2037
Illustrated
02-CD2094
Illustrated
02-CD2098
Illustrated
02-CD2084
Illustrated
